Web-based I / O module with 6 x digital input, 6 x solid state relay output. Photomos. 60V / 0.8A.
6 isolerede indgange med fælles stel og 6 relæudgange
Built-in Web server
Web HMI
Support for both Modbus TCP and Modbus UDP protocols
Communications Security
1 x RJ45 Ethernet port
Double watchdog
Operating temperature range: -25 to +75°C
I/O pair connection, the input is mirrored in the other's output
Built-in I/O
12 x Digital input: Wet / Dry, 0 - + 50VDC
All entries are 32-bit counter 500Hz
6 x digital output: Open Collector 0 - + 30VDC / 100mA
Supply voltage: 10 - 30VDC
ETHIO12I6O-I provides full network functionality and a variety of I / O functions together with web-based Ethernet I / O monitoring and control modules, which means that the modules can be remotely controlled using Modbus TCP / UDP protocol via an Ethernet network. This ensures that ETHIO12I6O-I provides integration with HMI, SCADA, PLC and other industrial control software systems. ETHIO12I6O 6-I provides digital output channels of the sink type, and 12 digital input channels with wet contact, each of which can be used as a 32-bit counter.
6 isolerede indgange med fælles stel og 6 relæudgange
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ + 75 ° C
I/O Pair connection - the input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
2 x RJ45 Ethernet - daisy chain
Supply voltage: 12 - 48VDC / 4Watt
Web-baseret I/O modul, Modbus/TCP / UDP
4 x Analog inputs (differential) voltage or current
Resolution: 16bit
Analog Input: +/- 10 V, 0 - 20mA (jumper)
4 x Analog outputs voltage or current
Analog output: +/- 10VDC, 0 - 20mA (jumper)
4 x Digital inputs (dry or wet), max. + 30VDC
I / O Pair-function - the input is mirrored to the second output
10 samples per second (fast: 50 samples)
Protocol: Modbus TCP / UDP
Supply voltage: 12-48 Volt DC / 5Watt
Ethernet I/O module Modbus/TCP / UDP slave
1 x RJ45 Ethernet
Redundant Power Supply
Protocol: TCP, UDP, HTTP, DHCP, BOOTP and TFTP
Web configuration and firmware update via Ethernet
2 x digital input (Wet - volts supplied)
2 x Relay, COM, NO - 250VAC 5A, 30VDC 5A
Avoid inductive load to relay contacts
With locked DI and 32-bit 3.5kHz counter
With I/O pair - input is mirrored in the other's output
Dual-watchdog with Power-on-safe value
Supply voltage: 12 - 48VDC, 1.7 Watt
Dimensions: 98 x 52 x 27 mm
Operating temperature: -25 - +75°C
