Electric door lock for 12 or 24 volts

Electric door lock that is locked without tension.
Holding force 1000 KG
supply: 12 / 24V DC 130 / 65mA when activated
Suitable for Scandinavian types
Operating temperature: -20 ° C to + 40 ° C
Multi voltage 12-24V AC / DC
approved for use in fire-resistant doors E120 / A120 / EI120
Fail secure (PTO): SL 510
Fail safe (PTL): SL 511
Latch bolt adjustable left / right
Built in "By status" sensor
Status monitoring: latch, anti-thrust bolt & amp; live handle
Mechanical key override

DOORLOCK-MAG1
4,609.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Suitable for use in high-traffic applications. Suitable for security applications such as perimeter doors, entrance doors, gates and other applications in office, commercial and industrial premises as well as entrance doors and common areas in residential areas.

Active: Locked with or without excitement

Certifications
godkendt til brug i brandsikre døre E120/A120/EI120
Driftstemperatur
-20°C till +40°C
Forsyning
12/24V DC 130/65mA ved aktivering
Fuld belastning
1000 Kg
Sensor
Built in ”Door Status” sensor
Sikkerhed
Fail secure (PTO): SL 510 Fail safe (PTL): SL 511
