HMI 4.3" Controller with touch panel, RS485 bus, MODBUS RTU, C and Ladder. RTC. 12 - 48VDC

4.3" HMI control panel for I / O modules
LCD color display with touch
Library for useful applications
RS485 serial port
Modbus RTU protocol
Supply voltage: 12 - 48VDC, 2.5 W
Dim: 126 x 92 x 29 mm
Wall mounts in wall-back piece 86 x 86 mm
Operating temperature: -20 - +50°C

HMI4.3"SER-I
2,212.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

HMI 4.3 inch series is a small touch HMI with high resolution TFT color touch screen and fit into regular electric wall mounted outlet. In addition, it is seamlessly integrated with many I / O modules and presents beautiful, flexible and custom image frame. In short, it is the best choice to upgrade the mechanical switch to intelligent control points.

For PLC users delivers HmiWorks Ladder designer, and for IT users, C-language environment is supplied. In particular, it only takes no more than 30 minutes to learn how to create an application program of devices in the TPD series when using Ladder designer. With all the functions supplied, TPD Series Touch HMI devices must be the most cost-effective HMI device that has ever been on the market.

CPU
32 bit RISC 80 MHz
Dimensioner
126 x 92 x 29 mm
Display
480 x 272 TFT skærm på 4,3” med 16 bits farve dybde
Forsyningsspænding
12 - 48VDC, 2.5W
Hukommelse
16
Montering
Panel
Porte
Seriel RS485 (maks. 115,2 Kbits/sek) og USB
Software
Software til download og udvikling af brugerprogrammer medfølger
Stik
Seriel port: Skrueterminal USB: Type A mini hunstik
