RFID reader Mifare and QR code. 13.56MHz, Wiegand 34 interface. Wall mounted. Indoors. 12vdc.

RFID with QR code reader
125kHz EM400x
13,56MHz Mifare Ultralight
Built-in buzzer for audio notification
can read multiple formats
With CPU watchdog
Power supply: 12V DC
Output: RS232, RS485, Wiegand 26/34 bits

1,609.00 kr
Excl. VAT
Quantity
Physically in stock
ADD TO CART
Product number RFID-MR-QR
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

Interface Wiegand 26/34bit
RFID 13.56MHz Mifare,

It can be connected online and offline access control. Scan the barcode or QR code to register the access incidents.
Built-in buzzer for audible notification.
Used with EM Card / Mifare card / Felica card / DESFire card / QR code / barcode.
CoverTamper .
Can read multiple formats. With CPU watch dog function to prevent malfunction.
OEM / ODM projects development.

Specification
RFID frequency: 125KHz ASK / FSK 125KHz / 13,56MHz

Existing cards : EM 4001, EM 4102 compatible / TEMIC 5557 / Mifare S50, S70, Ultralight, NFC card

Output Format (interface), RS-232 / RS-485 / Wiegand 26 / 34bits

Mounting: Surface Mount

Power Input: DC 12V
