12U 19 ”wall cabinet rack, 51.8cm deep, glass door, black
Black 19" rack cabinet at 12U
Wall mounting
Glasfront
Handles and lock for 635 x 600 x 600mm, built-in dimensions are 500 x 518mm
Mounting: Desktop or Wall Mount
Construction: Heavy Duty Cold Rolled Steel
Color: Black (Standard), or special colour on requist
Support Micro ATX M/B (120ATXR) (Max. to 9.6" x 9.6")
Drive Capacity: 2x 5.25" CD-ROM & 2x 3.5" FDD &1x 3.5" HDD
Power Supply (Optional): PS/2 Size Single or Mini Redundant ATX P/S (Rear Installation) Max. Depth 190mm
Cooling: 1x (120mm = 90.0CFM ea.) Fan
Front Door: Single Door With 2 Thumbscrews
Air Filter: Inside Front Danel (Washable)
Connector Port (Front): 2x USB Ports (on special request)
Thermal Management Card
Indicators: LEDs for Power ON/OFF, HDD Active, Fan, Temperature
Flexible Hold Down Bar Designed
Switch: Power ON/OFF, System Reset, Buzzer Reset
Dimensions (W x H x D): 400 x 177 x 420mm (15.7" x 7.0" x 16.5")
GW: 15.0 kgs / 33.1lbs
Humidity:55% - 95% Non-condensing
Power supply,DVD, Floppy is not included.
Cabinets in special dimensions, colors and with company logo can be offered to order. Contact us.
Black 19" rack cabinet at 12U
Wall mounting
Glasfront
Handles and lock for 635 x 600 x 600mm, built-in dimensions are 500 x 518mm
Mounting housing with DIN rail
IP65
Switch 14 module length
Flangeantal 4
Transparent front
Polycarbonate
RAL 7035 (light gray)
Dimensions 280 x 190 x 123mm
-40 - + 120 ° C
IP66 tight
Polystyrene, cover screws Polyamide, glass fiber reinforced
RAL 7035 (light gray)
Dimensions 182 x 180 x 84mm
Impact strength IK07
Protection class II
Insulation AC: 690V
Insulation DC: 1000V
Halogen free
-25 °C- 40 °C
Bundkort: Micro-ATX (medfølger ikke)
Ledige drevpladser: 1 x 5¼” og 1 x 3½” eksternt (bag frontlåge), 1 x 3½” internt
Strømforsyning: PS/2 standard(medfølger ikke)
Stikudskæringer: 2 x DB25 stik
Stik monteret i kabinet: 2 x USB i fronten til tastatur
Indikatorer og Kontakter: Lamper viser harddiskaktivitet, system tændt, blæser og temperatur
knapper til RESET, højttaler og tænd/sluk
Blæser: 90 x 90 mm medudskifteligt støvfilter
Medfølgende tilbehør: Skruer til drevmontering og vægbeslag. Monteret håndtag
Mål: (H x B x D) 177 x 307 x 421 mm
Vægt: 12 kg.
