Gigabit switch - managed

Gigabit managed Ethernet switche fra Antaira er ideel til anvendelse til produktionsanlæg. De er monteret i metalkabinet med DIN-skinnebeslag. De har alle redundant strømtilslutning. De har udvidet temperaturområde og derved perfekt til de krævende opgaver. Produktprogrammet er en bred vifte af non-PoE plug-and-play-modeller.

Gigabit switch - managed

Underkategorier

Der er 12 varer.

Viser 1-12 af 12 element(er)
24 ports Industriel...

24 ports Industriel 10/100/1000Mbit + 4 x 100/1000Mbit SFP, combi, managed PoE switch. Rack. -40 - +75°C, 46 - 57VDC

24 x 10/100/1000Tx IEEE 802.3 af/at, PoE+ Gigabit Ports (30W/Port) + 4 x Gigabit Copper/SFP combi porte
4 x 10/100/1000Tx RJ45 + 4 x 100/1000 SFP Slots
Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB
Sikkerhed: 802.1x (Port Baseret, MD5/TLS/TTLS/PEAP Encryption), HTTPS, SSH og SNMPv3
Redundant: Proprietær Ring (Ultra-High-Speed Recovery Time < 20 ms), RSTP/STP (802.1w/1D), MSTP
48VDC power input (46-57 VDC for PoE af, 53-57 VDC anbefales for PoE at) & 2 Relay Outputs
Temperatur: -40° - 75°C - polaritetsbeskyttelse
Overload beskyttesle
1U Rackmonteret design
IP30 tæt

Pris Ring for pris
Varenummer ANR-LNP-2804GN-SFP-T
På vej ind
  • 8-Ports industriel PoE+...

    8-Ports industriel PoE+ Gigabit managed switch 4 RJ45 porte og 4 SFP porte

    Network Broadcast Storm Protection
    4 x 10/100/1000Tx Gigabit RJ45 Porte
    4 x 100/1000Fx SFP Porte
    IEEE 802.3af/at Compliant op til 30 Watts per Port
    Netværk Redundans: RSTP/MSTP, and G.8032 ERPS (Recovery time <50ms)
    Konfiguration: Web Console, Serial, CLI Command
    IGMP v1/v2
    QoS (IEEE 802.1p) and CoS/ToS
    IEEE 802.1Q VLAN, SNMP v1/v2c/v3
    Redundant strømforsyning: 48~55VDC
    Indbygget Relæ Output for Port Break Alarm
    System advarsel indstilling for Automatisk advarsel via E-mail
    DIN-skinne og væg montering
    Driftstemperatur - STD: -10° to 70° C
    Dimensioner: 54 x 142 x 99 mm

    Pris 5.935,00 kr.
    Varenummer ANR-LMP-0804G-SFP
    På vej ind
  • 12-Ports Industriel Gigabit...

    12-Ports Industriel Gigabit PoE+ managed switch, 10 x RJ45, 2 x SFP porte, 48-55VDC

    8 x 10/100/1000Tx IEEE 802.3at/af Compliant with 30W/Port
    2 x 10/100/1000Tx
    2 x 100/1000Fx SFP
    Netværk redundans: STP/RSTP/MSTP
    G.8032 ERPS (Recovery Time <50ms)
    IPv4/IPv6, and DHCP Option 66/67/82
    Modbus/TCP Protocol til Device Management and Monitoring
    Konfiguration Web Console, Telnet, CLI Command
    PoE Ping Alarm Funktion til PoE Porte Power Recycle
    IGMP v1/v2 for Multicast Traffic Filtering
    QoS (IEEE802.1p/1Q), CoS/ToS
    IEEE802.1Q VLAN
    Netværk sikkerhed with IEEE802.1X
    SNMP v1/v2c/v3, HTTPS, and SSH/SSL
    Auto advarsel via E-mail, Relay Output
    Driftstemperatur: -10~70°C
    Forsyningsspænding: 48 - 55VDC

    Pris 7.175,00 kr.
    Varenummer ANR-LMP-1202G-SFP
    På vej ind
  • 8 ports Industriel...

    8 ports Industriel 10/100/1000Mbit + 2 ports 100/1000Mbit SFP slot, managed switch. DIN-beslag. -10 - +70°C, 12 - 48VDC

    8 x 10/100/1000Mbit RJ45
    2 x 100/1000Mbit SFP slot
    Netværk redundant: STP/RSTP/MSTP, og G.8032 ERPS (Recovery Time <50ms)
    IPv4/IPv6, og DHCP option 66/67/82
    Modbus/TCP Protocol for Device Management og monitoring
    Konfiguration: Web Console, Telnet, CLI Command
    IGMP for Multicast Traffic Filtering
    Enhanced Network Security med IEEE802.1X, SNMP v1/v2c/v3, HTTPS, og SSH/SSL
    Auto alarm via e-mail, relæ output
    RMON Function for Efficient Network Monitoring
    Temperatur -10°C til 70°C

    Pris 4.672,00 kr.
    Varenummer ANR-LMX-1002G-SFP
    På vej ind
  • 10-Ports industriel Gigabit...

    10-Ports industriel Gigabit PoE+ managed switch, 8 RJ45 porte og 2 SFP porte

    8 x RJ45 10/100/1000Tx IEEE 802.3at/af Compliant with 30W/Port
    2 x SFP 100/1000
    Netværk redundans: RSTP/MSTP, and G.8032 ERPS
    Konfiguration: Web Console, Telnet, CLI Command
    IGMP v1/v2, up to 256 Groups
    QoS (IEEE802.1p) and CoS/ToS
    IEEE802.1Q VLAN, SNMP v1/v2c/v3
    PoE Ping Alarm Funktion til PoE Power Recycle
    System advarsel indstilling for Automatisk advarsel via E-Mail
    Redundant strømforsyning: 12~36VDC, (indbygget Voltage Booster)
    Metal IP30
    DIN-Skinne og væg montering
    Standard Operating Temperature: -10° to 70°C

    Pris 6.386,00 kr.
    Varenummer ANR-LMP-1002G-SFP-24
    På vej ind
  • 10 ports Industriel...

    10 ports Industriel 10/100/1000Mbit + 2 ports 100/1000Mbit SFP slot, managed switch. DIN-beslag. -10 - +70°C, 12 - 48VDC

    10 x 10/100/1000Mbit RJ45
    2 x 100/1000Mbit SFP slot
    Netværk redundant: STP/RSTP/MSTP, og G.8032 ERPS (Recovery Time <50ms)
    IPv4/IPv6, og DHCP option 66/67/82
    Modbus/TCP Protocol for Device Management og monitoring
    Konfiguration: Web Console, Telnet, CLI Command
    IGMP for Multicast Traffic Filtering
    Enhanced Network Security med IEEE802.1X, SNMP v1/v2c/v3, HTTPS, og SSH/SSL
    Auto alarm via e-mail, relæ output
    RMON Function for Efficient Network Monitoring
    Temperatur -10°C til 70°C

    Pris 5.507,00 kr.
    Varenummer ANR-LMX-1202G-SFP
    På vej ind
  • 7 ports industriel PoE+...

    7 ports industriel PoE+ gigabit unmanaged switch, 4 x RJ45, 2 x SFP

    4 x 10/100/1000Tx IEEE 802.3at PoE+ Compliant with 30W per Port
    1 x 10/100/1000Tx
    2 x 100/1000 SFP
    Auto MDI/MDI-X Function
    14Gbps Back-Plane (Switching Fabric)
    8K MAC adresse
    9.6Kbytes Jumbo Frame
    Surge Protection: 2,000 VDC
    ESD Beskyttelse: 6,000 VDC
    Strømforsyning: 12~36VDC
    Indbygget 1 x Relay Output for Power Failure Detection
    IP30 Rugged Metal Case Design
    Din skinne og væg montering
    Driftstemperatur -40° to 75° C
    Dimensioner: 46 x 99 x 142mm
    Vægt: 1.4 Lb

    Pris 3.675,00 kr.
    Varenummer ANR-LNP-0702G-F-24T
    På vej ind
  • 8 ports Industriel...

    8 ports Industriel 10/100/1000Mbit switch, DIN-beslag, -10 - +70°C, 12 - 48VDC

    8 x 10/100/1000Mbps, RJ45
    Netværk Broadcast Storm Protection
    Netværk redundant: RSTP/MSTP, ogh G.8032 ERPS (Recovery time <50ms)
    Konfiguration: Web Console, Serial, CLI Command
    IGMP v1/v2 snooping
    IEEE 802.1Q VLAN, SNMP v1/v2c/v3
    Redundant power input 12 - 48VDC
    Relæudgang til port afbrydelses alarm
    System alarm via e-mail
    DIN-Rail og vægbeslag
    Temperatur: -10°C til +70°C

    Pris 3.721,00 kr.
    Varenummer ANR-LMX-0800G
    På vej ind
  • 4 ports Industriel...

    4 ports Industriel 10/100/1000Mbit + 4 ports 100/1000Mbit SFP slot, managed switch. DIN-beslag. -10 - +70°C, 12 - 48VDC

    4 x 10/100/1000Mbit RJ45
    4 x 100/1000Mbit SFP slot
    Netværk redundant: STP/RSTP/MSTP, og G.8032 ERPS (Recovery Time <50ms)
    Modbus/TCP Protocol for Device Management og monitoring
    IPv4/IPv6, og DHCP option 66/67/82
    Konfiguration: Web Console, Telnet, CLI Command
    IGMP for Multicast Traffic Filtering
    Enhanced Network Security med IEEE802.1X, SNMP v1/v2c/v3, HTTPS, og SSH/SSL
    Auto alarm via e-mail, relæ output
    Temperatur -10°C til 70°C

    Pris 5.675,00 kr.
    Varenummer ANR-LMX-0804G-SFP
    På vej ind
  • 16 ports Industriel...

    16 ports Industriel 10/100/1000Mbit + 2 ports 100/1000Mbit SFP slot (combi), managed switch. DIN-beslag. -10 - +70°C, 12 - 48VDC

    16 x 10/100Mbps RJ45
    2 x 10/100/1000Mbit RJ45 (combi)
    2 x 100/1000Mbps SFP slot (combi)
    7.2 Gbps Back-Plane (Switching Fabric)
    Ethernet Ring Redundancy (Recovery Time <20ms)
    IEEE 802.1w Rapid Spanning Tree & IEEE 802.1d Spanning Tree Protocol
    IEEE 802.1x RADIUS
    IEEE 802.1p Class or Service for Traffic Classification & Prioritization
    QoS (Quality of Service)
    Port Based VLAN & IEEE 802.1Q Tag VLAN
    IGMP med Query Mode for Multi-Media applikationer
    Port Mirroring for Traffic Monitoring
    IP Address Security Management
    IP30 robust aluminum kabinet
    DIN-Rail eller vægmontering

    Pris 4.666,00 kr.
    Varenummer ANR-LNX-1802GN
    På vej ind
  • 4 ports Industriel...

    4 ports Industriel 10/100/1000Mbit switch + 1 x Gbit SFP slot, DIN-beslag, -10 - +70°C, 12 - 48VDC

    4 x 10/100/1000Mbps, RJ45
    1 x 100/1000Mbps SFP slot
    Netværk redundant: RSTP/MSTP, og G.8032 ERPS (Recovery Time <50ms)
    Konfiguration: Web Console, Telnet, CLI Command
    IGMP v1/v2, op til 256 grupper
    IEEE802.1Q VLAN, SNMP v1/v2c
    System alarm via e-mail
    Redundant power input – 12 - 48VDC
    IP30, DIN-Rail og vægbeslag
    Temperatur: -10 - +70°C

    Pris 3.483,00 kr.
    Varenummer ANR-LMX-0501G-SFP
    På vej ind
  • 8 ports Industriel...

    8 ports Industriel 10/100/1000Mbit + 12 ports 100/1000Mbit SFP slot, managed switch. DIN-beslag. -40 - +75°C, 12 - 48VDC

    8 x 10/100/1000Mbps RJ45
    12 x 100/1000Mbps SFP slot
    Redundant Ring - recovery time < 20ms over 250 units of connection)
    IP baseret bandwidth management
    IP police security function
    DOS/DDOS auto prevention
    DDM (Digital Diagnostic Monitoring) funktion (P1 ~ P8)
    IGMP snooping for filtering multicast traffik
    SNMP v1/v2c/v3, RMON and 802.1Q VLAN Network Management
    ACL, 802.1x User Authentication for security
    Multiple notification for warning of unexpected event
    Configurable by Web-based interface, Telnet and Console (CLI)
    Forsyningsspænding: 12 - 48VDC
    IP30 kabinet
    DIN-Rail og vægmontering

    Pris Ring for pris
    Varenummer ANR-LNX2012GN-SFP-T
    På vej ind
