Robust DIN-rail Fanless Embedded PC with Intel® Celeron® Processor N3350, 2 COM, LAN, 2 USB and DIO

Extreme cost-effective fanless embedded PC
Intel® Celeron® processor N3350 1.1GHz
2 x COM
2 x USB
1 x GbE LAN
8-bit programmable DIO for IoT gateway applications
Wide temperature range from -40°C to +70°C
12 to 24 VDC power input
OVP, UVP, OCP, RPP power protection design

EPC-N3350-DIN
Call +45 56 66 20 20 for price
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

The EPC-N3350-DIN is a DIN-rail fanless embedded PC designed to support the low-power Intel® Celeron® processor N3350. This DIN-rail industrial IoT gateway supports one DDR3L SO-DIMM slot with up to 8 GB system memory. Its proven rugged construction ensures reliable operation in harsh environments with an extended temperature range of -20°C to 70°C and anti-vibration up to 2G. Additionally, the wide range 12V-24V DC power input with a lockable terminal block type connector is suitable for industrial automation fields. The overvoltage and reverse protection lowers the risk of crucial data loss. The outstanding Intel® Atom™-based EPC-N3350-DIN is a perfect solution for industrial IoT applications such as smart factory automation and smart energy. The DIN-rail industrial IoT gateway offers an outstanding price/performance ratio with good quality. It comes with sufficient I/O connectivity while measuring only 31 x 100 x 125 mm. The I/O interfaces include two RS-232/422/485 ports, two USB 2.0 ports, one Gigabit Ethernet, one VGA and one DIO. Furthermore, the Intel® Apollo Lake-based EPC-N3350-DIN is equipped with two PCI Express Mini Card slots, one for mSATA storage card and another for 3G/GPRS/Wi-Fi connections.

CPU
Intel® Celeron® processor N3350 (1.1 GHz, Dual Core)
Chipset
SoC Integrated
Approval
CE FCC Class
Chok/Vibration
2 Gms (5 to 500Hz, amplitude 0.35 mm; operation/storage/transport)
Digital I/O
1 x DI/DO (8-bit programmable, DB9 female connector)
Dimensioner
(W x D(W x D x H) 31 x 100 x 125 mm (1.22" x 3.93" x 4.92") x H) 31 x 100 x 125 mm (1.22" x 3.93" x 4.92")
Driftstemperatur
-40°C to +70°C (-40°F to +158°F)
Ethernet
1 x 10/100/1000 Mbps
Forsyning
Terminal, 12 to 24 VDC, 1.15 to 0.62A (13.80 to 14.88W) Protection: OVP (±20%), reverse protection
Hukommelse
1 x SO-DIMM DDR3L-1866, up to 8 GB
Luftfugtighed
10% to 95% relative humidity, non-condensing
Montering
DIN rail Wall Mounting
OS SUPPORT
Windows® 10 IoT, Linux support package, AXView 2.0
PCI
1 x full-size PCI Express Mini Card slot with SIM slot (for wireless module ) 1 x full-size PCI Express Mini Card slot (for wireless module or mSATA
Porte
2 x RS-232/422/485
Storage
mSATA shared with PCI Express Mini Card slot (option eMMC flash onboard)
Udgange
1 x VGA
USB
2 x USB 2.0
Weight
0.3 kg (0.67 lb)/0.46 kg (1 lb)
