10.4 "HMI panel PC with Win7 Embedded (WES7). IPP65 / NEMA 4, resistive touch, 400nits, 800x600, COM, 10 - 30VDC, -20 - + 60 ° C
Rugged Panel PC for Industrial HMI - Fanless
OS: Windows Embedded Standard 7 SP1
CPU: Atom E3845, 1,91GHz, 64-bit quad core
RAM: 4GB
Hard Disk: 32GB SSD, slot for optional 16GB CF cards
Brightness: 400nits
Display: 800 x 600
Touch: 5-wire resistive (80% transparent)
COM: 2 x RS232 / RS422 / RS485
Ethernet: 2 x RJ45 Gigabit
USB: 2 x USB2.0
Supply voltage: 10 - + 30VDC, 22Watt
External dimensions: 291 x 229 x 53 mm
Panel cut-out: 274 x 211 mm
VESA: 75 and 100
IP65 front
Operating temperature -20 - + 60°C
