RFID UHF 865MHz reads Long Range, Ethernet, RS232 (option: RS485, Wiegand 26/34, 4G LTE, WiFi)

866 - 868MHz CE, equipped with 12dBI linear antenna
EPC Class 1 gene 2 (ISO18000-6C)
from 0 ~ 20 meters reading distance (depending on the surroundings)
from 0 ~ 7 meters of writing distance ( Depending on the surroundings)
Linux OS, Indy R2000 RFID chip, fast and precise reading rate
Ethernet connection
445 × 445 × 100 mm (l × W × H)
Operating temperature: -20 ~ + 60 ° C
IP65
Option: RS232 / 485, USB, GPIO, Wiegand 26/34, 4G LTE and WiFi
Option: Poe

RFID-865-12+
8,550.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Vehicle parking, intelligent weighing
Warehouse, logistics management
Asset management
Production line management

Afstand
Reading Range 0~15m Writing Range 0~5m
Antenne
Built-in 12dBi linear polarization antenna
Digital I/O
2-channel Relay Output, 2-channel Trigger Input, 2-channel level Output (optional)
Dimensioner
445mm×445mm×100mm (L×W×H)
Driftstemperatur
-20 ~ +60°C
Forsyning
DC 12V Input, PoE optional Power Assumption 2W(Standby), 10W(Working)
Frekvens
902 - 928MHz, 865 - 868MHz, RF band customized (optional) Frequency Hopping FHSS or Fixed Frequency Power Output +20dBm ~ +30dBm@50Ω load, 1dBm each step
Indikatorer og kontakter
Buzzer and LED(Power, Antenna, Reading/Writing)
IP-Tæthed
IP65
Luftfugtighed
5% ~ 95% (non-condensing)
Software
API(C++, C#) development kit (can be customized) Tag Operation Tag Protocol EPC Class 1 Gen 2(ISO18000-6C)
Tilslutning
10M/100M Ethernet interfaces Optional Interfaces RS-232/485, Wiegand 26/34 Optional Wireless Module 4G LTE or 802.11 WIFI module Optional I/O
Weight
3.8kg
