HDMI from transmitter via point to point network cable
HDMI from transmitter via IGMP network switch
Max. 16 receivers for 1 transmitter
Suitable for Video Wall
Excellent video adjustment
EDID emulation
This unit is sold as a spare part only as the transmitter module has been discontinued
This unit is sold as a spare part only as the transmitter module has been discontinued.
DANBIT refers to alternative item numbers: HDMI-MULTI-HD-R and HDMI-MULTI-HD-T or the 4K version HDMI-MULTI4K-R and HDMI-MULTI4K-T
HDMI-MULTI-R is an ideal solution for sharing an HDMI signal over the network.
HDMI-MULTI-R has several functions. The HDMI signal can be distributed over several screens as a video wall.
A signal is also transmitted over long distances using the network or split out to several screens.
For each monitor, 1 x HDMI-MULTI-R must be used.
HDMI-MULTI-R can be used in existing networks, which, however, require IP Multicast policies to be supported by the switches in the network (IGMP snooping) to avoid disturbances.
Several HDMI-MULTI-T transmitters can be placed on the network as transmitters and receivers only communicate with devices with the same ID - selected via a rotary knob on the transmitter and receiver.
The EDID information is supported via copy-in from monitor.
