WiFi concealed module for VESA PC
2 Way Power Splitter / Combiner
Kan splitte radiosignalet til 2 antenner
Ofte anvendt til Panel-antenner
1 dB insertion loss
Antenna to GPS, WiFi, 4G, LTE
5MHz bandwidth
Screw mounting
4 meter cable
temperature: -40 ℃ ~ + 85 ℃
Full IP67 waterproof
LoRaWan transceiver with digital inputs
LoRaWan transceiver with relay output (SPDT)
Supporter LoRa Class C Protocol
Serial Port: RS232 or RS485 (Transparent data)
Collects data to be transmitted to LoRa-Gateway Controller
Frequency: 868MHz - Range Up to 10 km
1 x Antenna 2dBi - SMA male connector
Configuration Port: Micro USB
Operating temperature: -40 - +70°C
Supply voltage: 5 - 24VDC
Dim: 79 x 60 x 24 mm
Range up to 50 meters in line of sight
point to point, multipoint
signal: RX +, RX (TX +, TX-), GND
connectors: DB9 female
Bluetooth version 2.0 + EDR
Frequency: 2.400 to 2.4835 GHz
Tx power: Max. 4dBm
Rx sensitivity: -96 dBm
Antenna: Rubber SMA female - external - 2dBi
Supply voltage: 5 to 40VDC, max. 17mA
Operating temperature: -40 to + 85 ° C
Dimensions: 87 mm x 34 mm x 18 mm. Antenna: 11 cm
