Vandtæt front

17 "TFT LCD (LED) resolution 5:4 1280x1024 FLAT PANEL
Intel® 7th Gen. Core™ I7 / I5 / I3 / Celeron®
Resistive touch. (option: Capacitive /projected)
8 x USB
2X DVI-D
4 COM ports
2 x DDR4 2133MHz SO-DIMM memory Up to 32 GB
2 x 2.5 "SATA III SSD with software raid 0.1 (Q170) / Without software RAID 0.1 (H110)
1 x Mini PCIe slot
1 x PCIe (X16) Slot ½ length
2 x GBE LAN, Support Wake-on-LAN, PXE
AC Input ATX 250W
OS Support Windows 10 IOT enterprise (64 bit)
Front panel IP65 Protection
Removable HDD / SSD Drive Bay
Wall mounting, VESA 75/100, Panel mounting

19” TFT-LCD, 1280 x 1024 (SXGA)
Brightness: 1,600 nits
Intel® Core ™ I3-8145ue Dual Core Processor (standard)
Intel® Core ™ I5-8365 quad Core Processor (option)
2x DDR4 SO-DIMM Socket, Supports Up to 2400MHz, 64GB
Integrated USB 3.2 Gen 2 supports up to 10Gbps
M.2 E Key Socket for Wireless Module or Intel CRF Module
Supports Ignition Sensing Function (IGN) (option)
Wide Range Operating Temperature -20°C to 70°C
Designed with Rugged Aluminum Die-casting Front Bezel
Flat IP65 Compliant Front Panel Protection
Panel / VESA / Rack Mounting
9~48VDC via 3-pin Terminal Block

21.5" Industrial Compact Size Panel PC
Flat Front Panel Touch Screen
Fanless Design
Intel 6th Gen. Core i3 (Standard) / I5 (option) CPU Built-in
1 x 260pin SO-DIMM DDR4 up to 16GB 2133MHz
DC 9 ~ 36V Wide-Ranging Power Input
Optional Projected Capacitive Touch Screen Support 7H Anti-Scratch Surface
High brightness 1,000 nits for option

12.1 "TFT
CPU Gen.6 I3 Standard (I5 Option)
with or without touch resistive, Projected capacitive 7h Anti Scratch surface
1 x 260-pin SO-DIMM DDR4 2100MHz Max. 16GB
2 x USB 3.0
1x 2½ "SSD Sata Bay
1 x Mini Pcie Slot Full Size
1xDB9 RS232 / 422/485, COM1, 1X RS-232 DB9 COM 2
2 x RJ45 GBE LAN RJ45
IP66 Front
Vesa Mount 100x100
319x245x51.7mm
1 x 3 Pin DC 9 ~ 36vdc
Windows IoT Support

12.1” Industrial Panel PC
Intel Apollo Lake N4200 (1.11 GHz) 4 Core, 4 Threads, CPU built-in
Onboard 4GB DDR3L 1603MHz max. 8GB (optional)
Flat front panel
P-CAP Touch
​Fanless Design
IP66 front
2x GbE LAN RJ-45
2x USB 3.0, 4x USB 2.0 (optional)
1x DB9 (RS232/422/485), 1x DB9 RS232
OS support: Windows embedded 7, Win7, Windows 10 IoT
Opt. 4G LTE/WI-FI/BT extension
Opt.: UPS built-in
Opt.: Isolated RS232/485.
DC 9 ~ 36V  Power Supply

Screen size 23.8"
1920x1080 FullHD
Capacitive Touch
Intel i3 Gen8 CPU
Option: other CPUs can be offered
IP65 Only Front
2x RJ45
2x RS232
4x USB3.0
1x HDMI, 1x DP
Panel/VESA mount
-20~60C
18~28Vdc
OS SUPPORT: Windows 10, Linux Ubutu, CentOS

19" TFT-LCD
Resolution: 1280x1024
7th Gen i5 CPU (other cpu can be offered)
2 x RJ45, 4 x USB3.0, 2 x RS232
9-36V DC 3-pin terminal block
-20 ~ 60° C working temperature
437.27 x 316.27 x 60.3 mm
Panel mounting/ 75 mm VESA mounting

65" outdoor solution
Can be delivered as
Monitor: with 2xHDMI, VGA input
Digital signage: 2xUSB2.0, 1x HDMI (input), 1x SD card slot
Android: 2xUSB2.0, 1xHDMI output, 1xRJ45, 1x Wifi, (Optional 4G LTE), Rockchip RK 3288, Arm 1.8Ghz,2GB RAM, 8GB SSD, Android 7.1
Windows: 2x USB2.0, 2x USB3.0, 1xRJ45, 1xWifi, Intel i5 Gen. 10 2.9Ghz, Chipset H510, 8GB RAM, 120GB SSD, win10/Linux
Broghtness 3000~4000cd/m
Support Portrait & Landscape display mode
IP65
-20~50℃

16:9 Ratio with 21.5”
1920 x 1080 pixel
CPU i5-8365UE vPro (i3, i7 is option)
1x HDMI, 1x DVI-D
2x RJ-45, 3 x DB9, 4x USB3.0
Fanless & Front Panel IP65'
VESA Mount 100 x 100
Magnetic I/O Port Cover
Aluminum Die Casting Housing
Windows 10, Windows 11, Linux

15.6" TFT, Resolution 1920x1080
CPU I3-5015U
1000 Nits
Light sensor, (auto dimming on special request)
IP64 front
1xRJ45
2x USB2.0
2x USB3.0
1x RS232/422/485
1x RS232
BT
Wifi
HDMI,VGA output

OS support Windows 10, Linux

19" TFT-LCD 250nits
Resolution: 1280x1024
Front panel IP65
Intel® Celeron® J1900,Quad-core, Up to 2.42GHz
4GB RAM onboard
2 x RJ45
1 x HDMI
4 x USB2.0
6 x RS-232 (2x DB9, 4x terminal)
9-36V DC 3 pin terminal block
-20 ~ 60° C working temperature
Panel Mounting/ 75mm VESA mounting
Dimensions 437.27 x 316.27 x 60.3 mm

19" TFT-LCD Panel PC
IP65 front
Resolution: 1280*1024
250 nits
5-wire resistive touch screen (capacitive touch on request)
Intel Celeron J4125/J6412 CPU / Core i5 /i7
RAM: 1x SO-DIMM DDR4 (celeron) max 16 GB, i5/i7 2x SO-DIMM DDR4 max 32 GB
1 x M.2 2242/2260/2280 SATA
1 x SATA (2.5'' SATA)
1 x M.2 2280 NVME
MPCIe: M.2 3042/3052 for 3G/4G/5G with built-in SIM slot, M.2 2230 WiFi & BT
2x RJ45 Intel i225V (on special request 2 more can be added)
USB: Celeron version: 4*USB2.0+2*USB3.0 (J4125/J6412), i5/i7 version 4*USB3.0+2*USB2.0
COM: 2x DB RS-232/422/485 port, 4*RS232 in expansion port
GPIO: 1* 10 bit GPIO Inside the expansion port
Power supply: 9-36V DC plug
Working temperature: With air flow -10 ~ 60° C
Anti-vibration with SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hour/axis
Anti-shock with SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
437.27x361.27x68.8mm
OS Support: Windows 10 / Ubuntu, CentOS
