Access is controlled by Smartphones via BT
Equipped with call button to request access
United pushbutton with light
Built in sounder
Up to 1000 users
Different user rights
3 functions: access with BT APP, access via query Exit
one administrator
BT: BLE4.2 (Low Energy)
BT range: up to 50 meters, depending on conditions
Compatibility: Android 5.0 and up, iOS9.0 and up
relay contact: NO / COM / NC (switching relay)
Supply voltage: 12 to 24VDC 1A
Operating temperature: -20 - + 70 ° C
Dimensions: 86 x 86 x 38 mm | material: plastic housing
ACCESS-PBT is ideal for controlling electronic door locks, both electric strike, electronic holding magnet, motorized door lock etc. ACCESS-PBT is Bluetooth smartphones o.li.
Compact design in all-in-one. Is equipped with a push button that can be programmed for multiple functions. Pressing, notify the "administrator" of desired access. Pressing, opening the door for a given time. Kirke ACCESS-PBT is a free APP (Blue Witch) which is available in the 2 App store.
administrator can give each user rights - days, times, etc. and download log data from the ACCESS-PBT.
Application drawing shows:
1 - ACCESS-PBT
2 - Steam power with lock-mode (an option)
3 - Electronic holding magnet (f. eg. DOOR-MAGMET +)
4 - Electric lock box or drop-bolt
Switch mode type
110-240 VAC for & nbsp; 12VDC / 3A
DC connector: 5.5 / 2.1 mm
AC / DC power supply for DIN rail mounting
100-240V AC, 50 / 60Hz, 1.1A
Output, 24V, 1.7A (40 Watt)
Screw terminal
Adjustable output voltage
Short-circuit, overload and surge protection
Compact dimensions: 40 x 100 x 90 mm
Working temperature: -20-70 ° C
Bluetooth BLE 4.2 (low energy)
Up to 200 users
With user rights
Up to 1000 event logs in memory
Export to Excel spreadsheet
Access with RFID chip (EM, 125kHz)
With LED indicator
APP for iPhone and Android
APP is Easiprox
Range up to 50 meters
Can be set to open by pressing in the APP or automatically when you are within range
With solid state relay - no wear and tear
Adjustable re-lock time 1 - 1800 seconds
3 lock mode: Re-lock, always open, always locked.
Vandal alarm
Supply voltage: 12 to 24VDC
Dimensions: 88 x 44 x 23 mm
8" smart access control system, face and ID QR, RFID
Measures body temperature
Interface: LAN, Wiegand, USB2.0
Relay output for electric lock on door/gate
Offline dynamic portrait mode
Face database: 50,000+
Recognition distance: 0.5 - 3 meters
Dual-eye recognition mode
Speed: better than 0.3 second
99.9% accuracy
Thermal IR meter: 32 - 45°C with alarm
Supply voltage: 12VDC /2.5A
Dimensions: 248 x 138 x 30 mm
Weight: 1.5 kg
IP65 sealed
Free management software (English)
Bluetooth BLE 4.2 (Low Energy)
Up to 200 user
With user rights
Up to 1000 event logs in memory
access with RFID tag (EM, 125kHz)
access by PIN code (4-8 digits)
with keypad backlighting
app for the iPhone and Android
Range up to 50 meters
Can be set to open at pressures in the APP or automatically once inside the selected range
With solid state relay - no wear
With vandal alarm
Supply voltage: 12 to 24VDC
Dimensions: 152 x 45 x 23 mm
Access control with learning function
Supported from a maximum of 15 wireless remote controls
Frequency band: 433MHz
Range: up to 50 meters (LOS)
Relay output for electric door lock (24V/3A)
Entry to Exit button
Selectable timers: 1, 3, 5, 10 seconds
Wall mountable with flanges
Dimensions: 83 x 62 x 30 mm
Plastic housing
