Powerful industrial GPU computer with Intel® Gen. 8/9 CPU I3 / I5 / I7 or Xeon CPU Support, 9~48VDC

Supports 9th/8th Gen Intel® Xeon®/Core ™ processor (35W/65W/80W)
Nvidia / AMD GPU Support up to 328mm
Intel Gen. 8/9, C246 Chipset
2 x DDR4 SO-DIMM, supports ECC/non ECC type up to 2666 MHz, 64GB
4 X 2.5" Hot Swappable SATA III HDD/SSD BAYS (MAX HEIGHT 15 mm)
1 x M.2 m Key operation (NVME), 1 x M.2 E key (CNVI)
VGA, HDMI, DP
6x USB, 1x UBS internal
2 x RS232/422/485
2 x Front Available SIM card slot for signal redundancy
Power 9~48Vdc, 220W
Dimensions 105x190x360mm (wxDxH)
Operating temperature -40°C to 70°C depending on CPU
9~48VDC via 3-pin Terminal Block
​Optional AC/DC or DC/DC 24V 480W Power Supply
Optional AC/DC or DC/DC 24V 1000W Power Supply

Call +45 56 66 20 20 for price
Quantity
On the way in
LÆG I KURV
Product number IPC-GEN8/9-GPU
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

CPU Supports 9th/8th Gen Intel® Xeon®/Core™ Processor (35W / 65W / 80W)
Chipset Intel® C246
Antenne 7x Antenna Holes
Dimensioner 105 x 195 x 370 mm
Driftstemperatur 35W CPU: -40°C to 70°C, 65W CPU: -40°C to 60°C, 80W CPU: -40°C to 50°C
Forsyning 9~48VDC via 3-pin Terminal Block
Hukommelse 2x DDR4-2666/2400MHz SO-DIMM, ECC/non-ECC Type Up to 64 GB
M.2 1x M.2 Key M 2280 Socket, Supports PCIe x4 NVMe SSD o
Montering Wall Mount / Desktop Mount / 19” Rack Mount / Face-up Mount
Netværk 5x GbE LAN, RJ45
Porte 2x RS-232/422/485 with Auto Flow Control (Supports 5V/12V), DB9
SIM kort 2x SIM Socket
SSD 4x 2.5“ Front Accessible SATA HDD/SSD Bay (SATA 3.0)
USB 2x 10Gbps USB 3.2 Gen2, Type A, 4x 5Gbps USB 3.2 Gen1, Type A
Weight 8 kg

Extreme Computing Performance
IPC-GEN8/9-GPU Extreme Computing Power starts with an 8th or 9th generation Intel® Xeon® or Core™ i3/i5/i7 (Coffee Lake and Coffee Lake-R) CPU, Intel® C246 chipset, and supports two sets of DDR4 -2666 ECC/non-ECC SO-DIMM up to 64GB and can support up to two 250W high-end GPU cards. With a total power consumption of 720W, it is easy to meet and exceed high efficiency application requirements. A precision heat dissipation and cooling design quickly dissipates heat and keeps the focus entirely on the breathtaking performance of the IPC-GEN8/9-GPU.
CMI technology for various I/O module expansions
CFM technology for current ignition sensor POE function
Versatile Mounting Methods (Wall/Stand/Face-Up/19"Rack Mount)
Military Standard Shock Vibration Proof
