Embedded PC, Pentium® N4200 up to 2.50 GHz, 4X RS-232/422/485, 9~48VDC

Pentium® Processor N4200
1x DDR3L SO-DIMM max. up to 8GB
Triple Independent Display (1x CDS, 1x VGA, 1x DisplayPort)
1x 2.5” SATA Drive Bay, 1x mSATA Socket
Rich I/O (2x LAN, 4x USB, 4x COM, 8x Isolated DIO)
2x Full Size Mini-PCIe Expansion Socket
Supports 2x PoE+ Function (with optional module)
Supports Ignition Sensing Function (IGN) (with optional module)
Supports CDS Technology for Convertible Panel PC
Built-in Two 2W Internal Speakers
9~48VDC via 3-pin Terminal Block

Call +45 56 66 20 20 for price
Quantity
Physically in stock
ADD TO CART
Product number EPC-N4200-CDS
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

CPU Intel® Pentium® N4200
Video 1x CDS, 1x VGA, 1x DisplayPort
USB 4x USB 3.0 (Type-A)
Operating Temp. -40°C to 70°C
Antenne 4x Antenna Holes
Forsyning 9~48VDC via 3-pin Terminal Block
Grafik Integrated Intel® HD Graphics 505
Hukommelse 1x DDR3L 1333/1600/1866 MHz 204-Pin SO-DIMM Socket (8GB max)
Lyd Realtek ALC888-GR
Montering Wall / VESA / CDS / DIN Rail
mPCIe 2x Full-size Mini-PCIe Sockets
Msata 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe Socket)
Netværk 2x GbE LAN Intel® I210
OS SUPPORT Windows 10
Porte 4x RS-232/422/485 with Auto Flow Control Support 5V/12V, DB9
SIM kort 1x SIM Socket
SSD 1x 2.5” HDD/SSD Drive Bay (SATA 3.0)
Weight 1.49 kg
Dimensioner 204.5 x 149 x 41.5 mm

Powered by Pentium® processor, EPC-N4200-IPP is a slim embedded computer supporting Convertible Display System (CDS) technology. The system is designed to be positioned as “One Computer, Two Appliances”, it can be used as both an embedded computer or a panel PC. Integrated with Intel® high-performance graphics, the system supports triple independent displays (CDS/VGA/DisplayPort) and enables smooth 4K2K (@60Hz) playback via DisplayPort.

EPC-N4200-IPP offers extensive connectivity including 2x GbE, 4x USB 3.0, 4x COM, 4x DI/4x DO, 2x full-size Mini-PCIe slot and 1x SIM socket. For storage requirements, the system provides 1x 2.5" SATA drive bay and 1x mSATA socket. Through the ready-to-use modules, users can easily add power ignition sensing and Power over Ethernet (PoE) functions for a variety of applications.

Featuring with rigorous industrial protections, wide temperature range, and wide range DC power input, EPC-N4200-IPP is appropriate for harsh environments and critical applications.
