Load Cell Model 1010, 1.25 - 5kN, Low Profile

Load Cell Model 1010 – Low Profile Single-Point Load Cell (1.25 kN to 5 kN)

Low profile single-point load cell, 1.25 to 5 kN, compact aluminum design. Ideal for platform scales, force measurement, and precision weighing applications.

Call +45 56 66 20 20 for price
Quantity
On the way in
ADD TO CART
Product number LC-MODEL1010
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

The Model 1010 Load Cell is a high-performance, low profile single-point load cell designed for direct mounting of weighing platforms and precision force measurement systems.


This load cell supports capacity ranges from 1.25 kN to 5 kN, and is engineered for optimal stability, accuracy, and long-term reliability.

It is built from durable materials (often aluminum) and designed to tolerate overloads up to ±400% of rated load.

Key applications include industrial scales, test benches, force measurement systems, packaging machines, and any environment where a low profile yet robust sensor is required. Thanks to its compact height and off-center loading capability, it is suitable for tight installation spaces.


Feature Highlights

  • Capacity range: 1.25 kN to 5 kN
  • Low profile, compact design for tight spaces
  • Off-center loading tolerance (single-point)
  • Overload protection up to ±400% of full scale
  • Aluminum construction with good stability
  • Suitable for platform scales, force measurement, and industrial weighing
