Support for setting up PAY terminals

MDB Male and Female
EXT-MCR
TEMP
GND
DOOR OPEN
DEX Male and Female
RS232

MDB Master / Slave Controller via USB
Simple API for integration
can function as VMC or payment terminal
USB-COM Port ACM Driver
Built-in relay, can be controlled via command
Power supply via USB or MDB
Does not provide power output on the MDB port
Technical demanding product - Support for setup / integration can be purchased

MDB Male and Female
DEX Male and Female

NOTE: Contract with Danbit A / S and User Agreement with service supplier MUST be established before purchase!

Payment system with touch display.
accept contactless, chip, magnetic stripe and mobilepay.
GSM antenna connector MMCX to 6 digital outputs. Can be programmed with the time difference when paying. To 6 deaktiveringsindgang2. Can be configured to disable the machine
can be connected to a vending machine, washing machine, door, etc.
Web-based control panel.
Communications Internet or WiFi or 4G
Support for setup can be purchased.
Supplied with SIM card (4G)
Supply voltage: 10 - 24VDC, 10 - 42VAC / 2Amp (power supply included)

MDB Cable with USB Converter
USB-COM Port FT232RL
for integrating PAY terminal into a PC system
Demo software included
Power supply: 24VDC / VAC @ 0.5A (not included)
Dimensions: 100 x 50 x 30 mm

Universal electric car charging stand for all EV vehicles
Allow two electric cars to charge at the same time
Smart design
Dynamic management of charging
Interface protocol: OCPP 1.6
Payment for parking and charging by payment card
Monthly fees apply
AC Input 230-400 VAC +/- 10 (2 or 3 phase)
Total Power output 2 x 22kW / 2 x 32A Max (load sharing)
Payment: Payment card, Google Pay, Apple Pay (option: MobilePay)
Communication: 4G
IP degree: IP55
Operating temperature: -25 C° to 55 C°
Dimensions: 520 x 360 x 260 mm
Charger cable not included. The user uses the cable that comes with their car.
