Excellent managed switch with 802.3bt PoE ++ to the harsh environment
ESW8G-M-SFP4P + is a 3 Layer Industrial Managed PoE ++ switch as 8 x 10/100 / 1000BASE-T ports with each port having a power up to 95 Watt, 2 x 10G SFP and 2 x 100 / 1000Base-X SFP ports for Single Mode and Multimode SFP modules with LC connector. Robust IP30 metal housing for stable operation demanding environments. Since ESW8G-M-SFP4P PoE + ++ series switch is capable of operating under a wide temperature range from -40 to + 75 ° C it can be placed in almost any difficult environment. ESW8G-M SFP4P + switch series with DIN rail mounting and wall mounting.
Is very suitable for:
PoE PTZ speed dome cameras
Network Devices
Thin clients
All in One touch PCs, point of sale (POS) and information kiosks
Remote digital signage
PoE lighting
802.3bt PoE ++ and Advanced PoE Power Output Mode Management
to meet the demand of various driven devices that use stable PoE power gives ESW8G-M SFP4P + switch series five optional PoE power output modes:
90W 802.3bt PoE ++ power output mode (Pins 1, 2, 3 6 + Pins 4, 5, 7, 8)
95W UPOE / POH power output mode (pins 1, 2, 3, 6 + Pins 4, 5, 7, 8)
30W end-voltage PoE power output mode ( pins 1, 2, 3, 6)
30W PoE power output mode mid-span (pins 4, 5, 7, 8)
60W Force power output mode (Pins 1, 2, 3, 6 + Pins 4, 5, 7, 8)
1588 Time Protocol of industrial computer networks
ESW8G-M SFP4P + is ideal for telecommunications and Carrier Ethernet applications, supports MEF-service delivery and timing of packet solutions for IEEE 1588 and Synchronous Ethernet.
