HD HDMI extender over IP med PoE - Digital Signage, sendermodulforHDMI
HD HDMI extender over IP med PoE - Digital Signage, sendermodulforHDMI

HD HDMI extender over IP med PoE - Digital Signage, sendermodul

HDMI video transmitter PoE
Suitable for video wall
With HDMI Loop Out
Delay of approx. 1 second from transmitter to receiver
HDMI 1.4a - H.264
By IP multicast use switch with IGMP Snooping
Range up to 100m
Cables Kat. 5th / 6
EDID Emulation
IR Transfer
1 x RJ45, 1 x DB-9, 1 x HDMI Input, 1 x HDMI Output
Supply IEEE 802.3af / at PoE +; 5V DC, 2A (not supplied)
As receiver, use HDMI-MULTI-HD-M

1,868.00 kr
Excl. VAT
Quantity
Physically in stock
ADD TO CART
Product number HDMI-MULTI-HD-T
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

Video H.264 format for video encoder/decoder. MPEG 1 Layer II format for audio encoder/decoder
Operating Temp. 0-50°
Andet EDID (Extended Display Identification Data) function
Båndbredde 15Mbps (max.)
Forsyning IEEE 802.3af/at PoE+ 5V DC, 2A
HDMI HDMI 1.4a
Kabel Cat5e/6 UTP cable
Kanaler DIP (64 channels)
Lyd 2-ch uncompressed audio
Opløsning Video In Resolution: 1080p @ 60/50 Hz 1080p @30/25 Hz 1080i @ 60/50 Hz 720p @ 60/50 Hz 480p @ 60/50 Hz 480i @ 60/50 Hz Video Out Resolution: 1080p @30/25 Hz 1080i @ 60/50 Hz 720p @ 60/50 Hz 480p @ 60/50 Hz 480i @ 60/50 Hz
Porte RJ45, 1 DB-9, 1 HDMI In, 1 HDMI Out
Protokol TCP, UDP, RTSP, RTP, DHCP, IGMP Snooping, Multicast, IPv4
Rækkevidde 100 meters (330 feet) over CAT5e/6 cable
Sikkerhed HDCP compliant
Standarder IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3af/at PoE+
Weight 290 g
Dimensioner 130 x 82 x 30.25 mm

HDMI extender over IP med PoE leverer en fantastisk full HD videodistributionsløsning.

Skal bruges sammen med et eller flere modtagermoduler HDMI-MULTI-HD-R

Netadapter 5V DC, 2A reguleretforPower Supply
5VDC 2 Amp (10Watt) power adapter from 100 - 240VAC. DC plug: 5.5 / 2.1mm

Switch mode type
100 - 240VAC to & nbsp; 5 VDC, 2 A
DC plug: 5.5 / 2.1mm

180.00 kr
Item Number: DC5V/2A-R-Q
Physically in stock
ADD TO CART
Quick view
HDMI Extender over IP network or CAT 5/6 cable with EDID HDMI extender over CAT. 5/6/7
HDMI Extender 1080p HD over IP network, with PoE, or point to point with PDS cable. Receier module. Purchase Transmitter

HDMI Video Receiver with PoE
Transmitter Module is purchased: HDMI-Multi-HD-T
Video Wall with a maximum of 64 units
H.264 Video Encoder / Decoder, IR transfer
Delay of approximately 1 second from transmitter to receiver
HDMI 1.4a
Connection over IP - Use switch with IGMP Snooping
Max. 64 Groups
Range Up to 100m - Point to Switch or to Transmitter
Cables Cat 6a. Good quality
Edid Emulation - possibly not on all screens, then buy it from Danbit
1 x RJ45, 1 x DB-9, 1 x HDMI exits
Supply IEEE 802.3AF / to POE + or 5V DC, 2a (not included)
Requires quality switch When used over IP
Dim: 130 x 82 x 30 mm

1,595.00 kr
Item Number: HDMI-MULTI-HD-R
Physically in stock
ADD TO CART
Quick view
