HDMI 4K60 KVM over IP Extender with PoE, 100 m Cat / 60 km Fiber, USB / RS232 / IR / Audio

True 4K@60Hz (4:4:4) video with full-bandwidth HDMI over IP

Up to 100 m over Cat5e/6 or 60 km over single-mode fiber

PoE (Power over Ethernet) input (approx. 15W) removes need for separate power supply

Built-in HDMI loop-out at transmitter for local display monitoring

USB KVM + RS232 + bi-directional IR and embedded audio support

Operating Temperature: 0 to 55℃

Power Supply: TX: DC 12V 1.5A, RX: DC 12V 1.5A

Compatible with Ethernet switches for scalable distribution, video wall, matrix deployments

Call +45 56 66 20 20 for price
Quantity
On the way in
ADD TO CART
Product number BOOST-HDMI150-U-4K
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

Input TX: HDMI, RX: RJ45
Output TX: RJ45, RX: HDMI
Operating Temperature 0 to 55℃
Resolution Max: 4K@30Hz 4:4:4
Power Supply TX: DC 12V 1.5A, RX: DC 12V 1.5A

High-performance AV-over-IP extender designed for modern installations demanding long-distance, high-quality video and full remote control. It delivers 4K@60Hz (4:4:4) video together with USB (keyboard & mouse), RS232, bi-directional IR, and audio over standard CAT5e/6 or fiber.

With support for up to 100 metres over copper (Cat5e/6) and 60 kilometres over single-mode fiber, this unit is ideal for large digital signage networks, control rooms, broadcast, surveillance, classrooms, or any environment where the source and displays are far apart.

Power over Ethernet (PoE) simplifies installation by enabling power delivery via network infrastructure (up to 15W). The built-in HDMI loop-out allows a local monitor at the transmitter side. It also works seamlessly with Ethernet switches for distribution, switching, and matrix-style deployments.

Control is flexible: front-panel buttons, IR remote, RS232 console, and web/Gui management. This unit supports video wall functionality and is TAA-compliant for procurement in regulated environments.


Feature Highlights

  • True 4K@60Hz (4:4:4) video with full-bandwidth HDMI over IP
  • Up to 100 m over Cat5e/6 or 60 km over single-mode fiber
  • PoE (Power over Ethernet) input (approx. 15W) removes need for separate power supply
  • Built-in HDMI loop-out at transmitter for local display monitoring
  • USB KVM + RS232 + bi-directional IR and embedded audio support
  • Compatible with Ethernet switches for scalable distribution, video wall, matrix deployments
