HDMI 4K60 KVM Fiber Extender, 60 km (Single-Mode) / 300 m (Multimode), with USB, IR & RS232

4K@60Hz (4:4:4) HDMI transmission over fiber

Up to 60 km single-mode or 300 m multimode distance

USB KVM, IR, RS232 control capability

Latency less than one video frame

Supports HDMI 2.0, HDCP 2.2, HDR, 3D

Power: 5 V DC, 2 A; maximum consumption ~5 W.

Operating temperature: -10 to 45 °C; storage: -30 to 70 °C.

Full audio support: LPCM 7.1, Dolby TrueHD, DTS-HD MA, ATMOS, DTS:X

Call +45 56 66 20 20 for price
Quantity
On the way in
ADD TO CART
Product number BOOST-HDMI60K-UF4K6
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

Input TX: HDMI, RX: 1 x SFP + 10G
Output TX: 1 x SFP + 10G, RX: HDMI
Operating Temperature -10 to 45℃
Resolution Max: 4K@60Hz 4:4:4 18Gbps
Power Supply DC 5V 2A

High-performance fiber optic HDMI KVM extender engineered for extremely long distances. It supports 4K@60Hz (4:4:4) video over fiber links—up to 60 km with single-mode and 300 m with multimode.

This extender integrates support for USB (keyboard & mouse), bi-directional IR, and full-duplex RS232, allowing you to control devices at the remote end. Only one control method may be active at a time (selectable via DIP switch).

Latency is under 1 video frame, giving responsive control and smooth video.

Other features include:

  • HDMI 2.0 / HDCP 2.2 support for modern content protection and display compatibility.
  • Support for LPCM 7.1 @ 192 kHz, Dolby TrueHD, DTS-HD MA, ATMOS, DTS:X audio formats.
  • USB ports: 1 × USB Type B (transmitter), 2 × USB Type A (receiver) for remote devices.
  • RS232 at up to 115,200 bps, full-duplex.
  • IR frequency 30–60 kHz, ±10° transmit / ±55° receive, up to ~5 m distance.
  • Power: 5 V DC, 2 A; maximum consumption ~5 W.
  • Operating temperature: -10 to 45 °C; storage: -30 to 70 °C.
  • Dimensions: 109.6 × 114.5 × 30 mm; weight: 270 g each unit.

This fiber KVM extender is ideal for installations such as broadcast, control rooms, data centers, long-distance signage, or any environment where the source and destination are far apart but you still require full control (USB / IR / RS232).
