Moxa OPT8-M9 8 x DB9 han, RS232 forbindelsesboks
Moxa: OPT8-M9
Der er 19 varer.
Moxa: OPT8-M9
2 x RS232 seriel porte med plug & play
1 x TITAN BSP9216B (chipset)
1 x DB25 han connector på kortet
1 x DB25 female til to DB9 han adapter kabler inkluderet
Bus: universal PCI (5V og 3.3V) 32 bit 33MHz
RS232 signal: DCD, RxD, TxD, DTR, GND, DSR, RTS, CTS, RI
Maks. bitrate: 921.6kbps
Hver port med 16 bit FIFO for transmit & recieve
IS support: Windows, Linux
0°C to 60°C
DB62 male to DB62 male 150 cm connection cable for connecting to the serial board
MOXA Opt 8A+
MOXA: OPT8B
Seriel kort til universal PCI, lav bagpladeUniversal PCI 3.3 / 5.0V
1x RS232
UART 16550 (16 Byte FIFO)
Speed 921 kbps
PCI Plug and Play
Drivers for Windows 95 to 7/2008 R2
Software compatibel with DOS, Windows 3.11, OS/2, Linux and div. Unix
Moxa CP-114IS
Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64)
4-ports RS232 PCI/ISA kort
Bus: PCI ver. 2.1 (32-bit) eller ISA (16-bit)
Op til 921.6 Kbps
Forsyning 110 mA max. (+5V)
4-port højhastighedskommunikationskort (2 porte til RS-422/485, 2 porte til enten RS-232 eller RS-422/485)
RS-485 ADDC ™ data kontrol eller ved RTS
Forskellige tilslutningsmuligheder
Dataoverførselshastighed på op til 921,6 Kbps
On-chip hardware flow kontrol
Overspændingsbeskyttelse og Optisk isolering til rådighed som indstillinger
Indbygget termineringsmodstand
MOXA CP -1141
Serielkort universal PCI, 128 bytes FIFO, optoisoleret
2 x RS-232/422/485, 2 x RS-422/485 multiport serielkort.
4 x RS-422/485 interface med ADDC op til 921.6 Kbps
RS-485 kommunikation med rækkevidde op til 1.2 km
Built-in 15 KV ESD
128-byte FIFO
Universal PCI kompatibel m. 3.3/5V PCI og PCI-X
Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64)
Windows 95/98/ME/NT/2000
Windows Server 2008 R2/2012/2012 R2/2016/2019 (x64)
DOS
Windows Embedded CE 5.0/6.0, Windows XP Embedded
Moxa: CP104UL-DB9
2 porte til RS232/422/485, med 2 KV iso., universal PCI
OS SUPPORT:
64-bit System Intel Itanium
AMD Athlon 64 64-bit CPU System
Microsoft Win 9x/ME/NT, Win 2K/XP/2003, Win CE
Linux 2.0.x / 2.2.x / 2.4.x / 2.6.x
DOS DOS
PCI Bus
Com3 : RS-422/RS-485
Supports RS-422/RS485
Communication Speed: 921.6K
Isolation: 3000V
Self-Tuner Inside
COM4 : RS-232
non-isolation
Plug & Play driver
Supports COM3 & COM4
ICP DAS VXC-182I
DB62(M) to 8 x DB25(F) Connection Box w/ Surge Protection
MOXA Opt8S
8 RS232 serielle porte, 3.3 og 5 V PCI bus
Seriel kort til universal PCI, 128 FIFO
Serielkort universal PCI, høj + lav bagpl. 128 bytes FIFO
