Både 3,3V og 5V
Key Features
• Support eight RS232 port in one card.
• Support isolated RS422 or RS485 interface for each port independdntly.
• Support UNIX & LINUX system driver.
• Support Windows 95/98/Me/NT/2000/XP system driver.
• Support DOS dirver.
• Support Auto-Data-Direction-Control (ADDC) feature in RS485 port.
• Support surge protector in TXD/RXD signal line.
System Structure:
• Intelligent PCIPORT Card.
• External cable with eight standard B25/DB9 connector (R801 cable or R804 cable).
• External cable to RS4232-8 box (option).
Serial Communication Controller
• Type: 16550A compatible with PGA support.
• Speed: 1.8432MHz. (can be used upto 7.3728MHz)
Hardware Compatibility:
• 3.3V & 5V PCI bus slot.
Connector type:
DB25 male connector. (with R801 cable)
DB9 male connector. (with R804 cable)
Dimension:
• Card: 141*106 mm.
P588U
Serielkort universal PCI, høj + lav bagpl. 128 bytes FIFO
4-ports RS232 PCI/ISA-kort
Bus: PCI ver. 2.1 (32-bit
Op til 921,6 Kbps
Splitterkabel medfølger ikke!
DB37 kan bruges til 4xDB9M eller 4xDB25
EOL ikke længere i produktion! sidste stk på lager
Serielkort universal PCI, 128 bytes FIFO, optoisoleret
Seriel kort til universal PCI, lav bagpladeUniversal PCI 3.3 / 5.0V
1x RS232
UART 16550 (16 Byte FIFO)
Speed 921 kbps
PCI Plug and Play
Drivers for Windows 95 til Win 7 / 2008 R2
Software compatibel with DOS, Windows 3.11, OS/2, Linux and div. Unix
