2 Ports ethernet PCI express server adapter med PoE+

ONLY 1 Left!

8-CH timers/counters
2-CH cascaded 32-bit timer with 1 MHz base clock
On-board multiple base clocks ranging from 100 kHz to 2 MHz
External gate control and clock inputs for each counter
Inverted gate signals for 4-CH synchronized frequency measurement
Multiple interrupt sources from counter outputs, timer outputs and external interrupt inputs

20MHz A/D på et PCI kort

Samtidig konvertering på 4 kanaler

Adlink PCI-9812

Supports a 32-bit 5 V PCI Express bus
24/48/96-CH digital TTL/DTL inputs/outputs
Emulates 2 industry standard 8255 PPI (mode 0)
Support Windows 7/8 X64/X86 and Windows 2008 R2
Output port status read back
On board 8254 timer/counter chip
Programmable interrupt source
12V and 5V power supply to OPTO-22 (Direct interface with OPTO-22)

16 optoisolerede indgange, fælles stel (minus) og 16 optoisolerede udgange,

Understøtter en 32-bit 5 V PCIe Express bus - LAV PROFIL KORT
16-CH isolerede digitale indgange
16-CH isolerede digitale udgange - Open-Collector
5000 VRMS optisk isolering
Synkestrøm op til 500 mA på hver isoleret udgang

Omformer DB25 han til RS422/485 terminalblok
Adapter med 5 skrueterminaler
Op til 15V
Til analog kommunikation
Moxa NP21103

Isolationen beskytter både computer og  måleresultaterne mod fejl, grundet forskelle i stelpotentialer.

Supports a 32-bit 5 V PCI bus
12-bit A/D resolution
Up to 100 kS/s sampling rate
32-CH single-ended or 16-CH differential inputs
On-board 1 k-sample A/D FIFO
Bipolar or unipolar analog input ranges
Programmable gains of x1, x10, x100
Automatic analog inputs scanning

100KHz 16Ch Analog Input A/D Card - High Gain.
16 Single-Ended or 8 Differential Analog Input Channels
Bipolar or Unipolar Input Signals
Programmable High-Gain x0.5, x1, x5, x10, x50, x100, x500, x1000
12-Bit Successive Approximation A/D Converter (AD774 or equivalent)
On Chip Sample & Hold
Two 12-Bit Analog Output Channels
16 Digital Inputs and 16 Digital Outputs
Integral DC-to-DC Converter for Stable Input Operation
37-Pin D-Sub Connector
Compact Size - only half-size PC
WIN3.1/95/NT

Axiom AX5488

IEEE-488 (GP-IB) interfacekort (IEEE-488.1)
NEC-chip PD7210
21 firmware-kommandoer
over 300 kByte/s
DMA 1-3
IRQ2-7
med Basic, C, Pascal
Windows driver
