Signal Conditioner / Display

Signal Conditioner / Display

There are 8 products.

Products per page:
25 50 75 100
Sort by:
Relevance Name, A to Z Name, Z to A Price, low to high Price, high to low
Showing 1-8 of 8 item(s)

Active filters

    • Load cell - Strain Gauge...

    Load cell - Strain Gauge data logger up to 6-wire, 16bit, 4MB memory, 20ms sampling time, Battery operation, USB

    16-bit strain gauge / weighing bridge amplifier - datalogger
    With temperature compensation
    Excitation sense 2.5VDC
    Bridge input: +/- 8mV Version: 16mV and 32mV
    4 Megabyte memory to log data
    USB and RS232, automatic baud rate up to 115.2kbit
    Programmable input ranges (0-2 VDC, 0-20 VDC)
    Battery operation - 10 year battery
    Acc.: Software to configure, download, plotting, analysis and an alarm (not supplied)
    Configurable alarm controls
    Measurement speed of from 20 milliseconds (channel 1) to 12 hours
    Robust aluminum housing
    coated printed circuit board for protection against moisture, corrosion

    Price 8,301.00 DKK
    Product code: LOG-MIBG
    On the way in
    Quick view
    • Programmable Load Cell...

    Programmable Load Cell Instrument and controller, LCD Display, Connection up to 16 Load Cell, IP66 NMEA 4X

    Top-class weighing instrument from Interface
    LCD screen, W x H - 117 x 86 mm
    Display up to four channel channels per screenshot
    With required Legal for Trade information
    32 scale accumulations
    Millivolt calibration, 5-point linearization and geographic calibration
    NEMA Type 4X / IP66 stainless steel enclosure
    Selectable A/D with measurement speed up to 960/second
    100 set points, 30 configurable
    64K uses built-in Non-V RAM
    Power for 16, 350 ohm load cells per A / D card
    Peak team

    Price Call for price
    Product code: LC-920I-UNI
    On the way in
    Quick view
    • Portable load cell...

    Portable load cell instrument. 4 Wire Strain Gauge input. Single pass calibration, direct, mV/V with TEDs

    Handheld 7-digit LCD screen
    4 Wire Full Bridge input
    with Peak, Trough, Net, Overload and Shunt Cal Indication
    Battery operation of 450 hours in power saving mode
    Keys for ON / OFF , Interval Selection, Peak / Valley Hold and Gross / Net
    Single Calibration (Direct mV/V) with double range for values ​​such as kg and lb
    Weighing only 250 grams
    IP65 / NEMA4
    TEDs Enabled to automatic Sensor calibration (IEEE1451 - Template 33)
    Buy Leather case
    Battery: 2 x AA

    Price 8,554.00 DKK
    Product code: INST-LOADCELL-HH
    On the way in
    Quick view
    • Portable road cell...

    Portable road cell instrument for strain gauge input. Multi-point calibration, direct, mV/V. Logging and graphing. With TEDs

    Sovereign Linearity Specifications
    Excitation Voltage: 3.3Volt
    Resolution: 24bit
    % FS: 0.0002
    Measurement speed up to 2400 samples per. Second
    High internal resolution (up to 500,000 Counts)
    IP67 Searched cabinet
    Battery powered (long battery life)
    128 x 64 Graphic screen with backlight
    More display modes (Peak / bottom, Delta, Live , gross and net)
    logging and graphing for PC (software is included)
    support Ted's template 33, 40 and 41
    Live calibration and multi-point calibration
    Dim: 170 x 94 x 42 mm
    Weight: 330 grams

    Price 13,369.00 DKK
    Product code: INST-LOADCELL-PSD
    On the way in
    Quick view
