8 port Managed switch 8 x 100/1000Mbit RJ45. Fiber 2 x 100/1000/2500Mbit SFP slot, PoE+, -40 - +75°C, 12 - 48VDC

  • IGS-10020HPT, L2+ Industrial 8-Port 10/100/1000T 802.3at PoE + 2-Port 100/1000X SFP Managed Switch

Managed Industry switch to harsh environment
Cybersecurity SSHv2/TLSv1.2
Ethernet Ring Protection
e-Mark Certified (vehicles/ITS)
Can support 2.5Gbit SFP module
8 port industrial Gigabit switch, RJ45 with PoE+
Intelligent PoE
2 port SFP 100/1000/2500Mbps
Supply voltage: 12 - 48VDC / 7A
PoE power budget: 60W at 12V, 120W at 24V, 240W at 48V
Redundant power supply connection
IGMP snooping, MLD snooping
IEEE 1588 Time synchronization protocol
Modbus TCP real time (SCADA)
Extended temperature range from -40 to +75 °C
DIN rail or wall mounting
Dimensions: 152 x 107 x 77 mm

ESW8G-M-SFP2
5,481.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

ESW8G-M-SFP2 Industrial 8-Port Gigabit 802.3at PoE + Switch, is equipped with robust IP30 metal case for stable operation in heavy industrial demanding environments.

IP30 industrial protection and high level of immunity against EMC and electrical overvoltage. Wide temperature range from -40 to +75°C, the ESW8G-M-SFP2 can be placed in almost all difficult environments. Is for DIN rail or wall mounting.

Redundant Ring, Fast Recovery for Surveillance Systems is the ESW8G-M-SFP2 with redundant Ring technology and fast self-recovery prevents interruptions. Advanced Redundant Ring technology, Spanning Tree Protocol (802.1w RSTP), and redundant power supply system in the customer's industrial automation network enhance the system's reliability and uptime in harsh factory environments.

The ESW8G-M-SFP2 protects the customer's industrial network connection with switch recovery capability, which is used to implement fault-tolerant Ring and Mesh network architectures. If the industrial network was interrupted by accident, the error recovery times can be less than 50 ms to bring the network back to normal operation.
