Managed Industrial Gigabit switch. 24 x RJ45, 2 x 24
SFP ports PoE+, 30 watts per port
Total PoE power is 390 Watt
PoE voltage output: 54VDC 30W maximum.
24 x 10/100/1000Mbit RJ45
2 x 1000Mbit SFP slot
2 x uplink SFP or RJ45
Layer 2 switch
IGMP Snooping (Multicast Protocol)
Port mirroring
Operating temperature: -10 - +50°C
Supply voltage: 100 - 240VAC
Dimensions: 442 x 305 x 45 mm (1U)
Weight: 4.4kg
| Operating Temp. | -10° ~50° C., Luftfugtighed 0 ~ 95% ikke-kondenserende |
|---|---|
| Andet | Management L2 switch |
| Fiber | 2 x 1000 Mbit SFP porte |
| Hukommelse | 16.000 MAC adresser, 12 Mbytes buffer |
| LED | Power, Ports |
| PoE | 24x PoE pote (30W pr. Port total 390W) |
| Porte | 24 x 10/100/1000 Mbit ethernet ports support IEEE 800.3 af/at. 2 x 10/100/1000 Mbit uplink ethernet ports. 2 x 1000 Mbit SFP porte. |
| Strømforsyning | 100 ~ 240 VAC |
| Switch kapacitet | 56Gbps |
| VLAN | Port- baseret VLAN |
| Weight | 4.35 Kg |
| Dimensioner | 44 x 315 x 442mm (H x B x D) |
24-port Gigabit Ethernet switch with PoE Plus, which can deliver more power (30 W) than the normal standard PoE (15.4 W).
Can supply other devices on the network with power via the network cable (Power over Ethernet or PoE +) as a power supply for these devices is unnecessary. Of course this requires that devices support PoE.
Managed Switch with central administration via web browser and SNMP. Each port status can be displayed on a Web page.
ESW24L2-POE can also be configured for port security and port mirroring.
Port Security ensures that only devices with the configured MAC address to connect to the selected port
With port mirroring can gates monitored all traffic coming through the monitored port will also be sent to another port.
Supports authentication via RADIUS server
ESW24L2-POE has 2x SFP SX / LX, 2x Gigabit Ethernet uplink and a wide variety of standards. Supports port-based VLAN, which among other things is well suited to easily create rapid virtual network in a business with high security. VLAN and other features are easily accessible when the switch among other things can be configured directly in a browser.
IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX, IEEE802.3ab 1000BASE-T, IEEE802.3x flow control, IEEE802 .3ad Port Trunk with LACP, IEEE802.1d Spanning Tree Protocol, IEEE802.1w Rapid Spanning Tree Protocol, 802.1p Class of Service, IEEE802.1Q VLAN tagging, IEEE802.1x Port Authentication Network Control
