7-channel 4-20mA current data logger, speed 20ms to 12 hours, 16bit resolution, 4MB of memory, Battery operation, USB

16-bit 4-20mA to-digital converter
With temperature compensation
4 Megabyte memory to log data
USB and RS232, automatic baud rate up to 115.2kbit
Input ranges (4-20mA, version with 0-50mA)
Battery operation - 10 year battery
Tilkøbes: Software for configuring, downloading, graphing, analysis and alarm reporting (not included)
Configurable alarm controls / overvoltage control
Measurement speed from 20 milliseconds (1 channel) to 12 hours
Robust aluminum housing
Coated printed circuit board for protection against moisture, corrosion

LOG-MFC
5,996.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Data loggers with 7 channels input, battery-operated, stand-alone high precision to 4-20mA by up to 4MB flash memory.
Input current signals may be from sensors, transducers, transmitters or other conventional power sources. Its built
temperature channel provides environmental monitoring and temperature compensation.
Its aluminum body makes it ideal for the toughest industrial environments.
Plug Play USB port and versatile user-defined equations simplify the conversion of the unit.
16-bit ADC makes it suitable for science and laboratory purposes where accurate and precise measurements are critical.

Logger the memory capacity

Sampling interval Enabled Channel Logging capacity

1 minute 1 8 year

1 minute 2 4 years

1 minute 8 1 year

10 seconds 1 484 days

10 seconds 2 242 days

10 seconds 8 60 days

1 second 1 48 days

1 second 2 24 days

1 second 8 6 days

100 milliseconds 1 4 days

100 milliseconds 2 2 days

100 milliseconds 8 14.4 hours

Alarm
2 x programmerbare alarmer per kanal
Batteri
Op til 10 år
Dimensioner
88 x 64 x 24mm - vægt: 200 gram
Kanaler
7 stk. strøm indgange 0-20mA
Måleområde
0-20mA, version 2 er 0-50mA
Software
Site View til opsætning og visning skal tilkøbes
