6 x Digital input, 6 x Relay output via Ethernet for industrial control applications. 2 x RJ45 daisy chain PoE

6 x Digital Inputs - Wet (active at DC in)
6 x Power relay outputs - 24VDC / 250VAC / 5A
Protocol: Modbus TCP / UDP
2 x RJ45 Ethernet interface
With built-in network switch - with the daisy chain
I / O Pair-function - the input is mirrored to the second output
Digital inputs with counter - max 500Hz
the minimum pulse width: 1 ms
Screw terminal
Supply voltage: PoE or 10 - 30VDC / 3watt
PoE is NOT continued to LAN port 2 (data only)

ETHIO6I6PR-P2I
2,373.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

ETHIO6I6PR-P2i give 6 digital switch channels to a wet contact 6 and electromechanical relays from form A. It has optical isolation to 3000 VDC of the transient over-voltage protection and has no channel-to-channel isolation. Each input channel can be used as a 32-bit counter. Ignition value and ensure value for the relay is programmable.

Note: When connected inductive loads to the relays, there may be a large electromotive force when the relay is activated because of the energy stored in the load . These flyback voltages can damage the relay contacts and shorten the lifetime of the relay sharply. Limit these flyback voltages at your inductive load by installing a flyback diode for DC loads or metal oxide varistor to vekselstrømsbelastninger.

Digitale indgange
6 stk. digitale Logisk 0: 0 - 4 VDC, Logisk 1: 10 - 50 VDC
Digitale udgange
6 stk. relæudgange: AC: 250 V og 5 A eller DC: 30 V og 5 A. Skiftetider Lukke/åben er 7ms / 3 ms
Forsyning
10 - 30 VDC, 2,5 W via klemrække eller PoE
Netværk
10/100 Mbit m/RJ45-stik
Protokoller
Modbus/TCP, TCP/IP og UDP
Tæller
Indgange kan virke som 32 bit tæller, maks. frekvens 500 Hz
