HMI panel / PLC Controller

DANBIT delivers i.a. touch HMI devices designed for home / building automation and other applications. Several have many common features, such as a high-resolution touch screen, RTC and a variety of communication interfaces, including RS-232 / RS-485, Ethernet, USB. But each still has its own specific features for its respective target applications. The series is the rubber keyboard, IP-65 waterproof front panel and DIN Rrail / panel...

More

HMI panel / PLC Controller

There are 8 products.

Products per page:
25 50 75 100
Sort by:
Relevance Name, A to Z Name, Z to A Price, low to high Price, high to low
Showing 1-8 of 8 item(s)

Active filters

7" 16:9 ViewPAC with...

7" 16:9 ViewPAC with Cortex-A8 CPU and WinCE 7.0 HMI display, RS232/485, USB, Ethernet

Cortex-A8, 1 GHz CPU
7" TFT LCD with Touch
Front panel: NEMA 4/IP65
Windows CE 7.0
512 MB SDRAM and 256 MB Flash
16 KB EEPROM128 KB MRAM for data retention
1 x microSD socket with one microSD card
1 x 10/100/1000BASE-T Ethernet Port
2 x Serial Ports (RS-232/485)
2 x USB 2.0 (host)
Built-In Real-time clock
2 x LED Indicators
Audio with Earphone-out
Built-In dual Watchdog Timer
Panel mounting, VESA Mounting (75 mm x 75 mm)
IP65 Compliant Front Panel
213 x 148 x 44 (W x L x H)
Operating Temperature: -10 ~ +60 °C
 +12 ~ 48 VDC , 6W, POE
Price Call for price
Product code: HMI7-WINCE7.0
On the way in
Quick view
    • HMI 4.3" Controller Panel...

    HMI 4.3" Controller Panel with Touch, 1 x RJ45 Ethernet, 1 x RS485 1 x RS232.Modbus TCP / RTU. 12 - 48VDC / PoE

    HMI Panel with LCD Display, Ethernet and Com Ports
    Can be connected to most of the manufacturer's I / O modules
    Power supplied from PoE or 12 - 48VDC / 2.5 Watt
    RS-485 (with self-tunes) < Br> RS-232 (RX / TX / GND)
    RTC - Real-time tour
    GUI design
    Free HmiWorks development tools
    supports C and Ladder designer
    design suggestions from manufacturer
    Modbus TCP / RTU protocol
    Dim: 140 x 87 x 41 mm

    Price 4,475.20 SEK
    Product code: HMI4.3"SER-IC
    Physically in stock
    Quick view
    • HMI 4.3" Controller Panel...

    HMI 4.3" Controller Panel with Touch. 1 x RS232, 1 x RS485 Bus, 1 x RJ45 Ethernet, PoE, Ladder, C, Modbus / TCP / RTU

    High resolution Color Touch screen
    Poe (power over Ethernet)
    RS232 Port, RS485 Bus
    USB Download Port
    RTC (Real Time Clock)
    Gui Design
    Free HmiWorks Development Tool
    Supports C language and ladder designer
    Modbus / TCP, Modbus / RTU and DCON protocol
    Size: 126 x 92 x 29 mm
    Operating temperature: -20 ~ 50 ° C
    supports custom third-party protocol (C-language)

    Price 4,475.20 SEK
    Product code: HMI4.3"SER-ETH
    On the way in
    Quick view
