12VDC / 3A (36Watt) DC-DC converter from 8-40VDC. In molded aluprofile. IP68. Not galvanic isolated

Input from 36 - 75VDC
Output 12VDC Max. 10A (120watt)
92% Efficiency
synchronous rectifier technology
IP65
Dim: 110 x 70 x 23 mm
CE Rohs

MAX 12V 0.7A (8.4 Watts)
USB to 2.1x5.5 mm plug
To supply 12V/0.7A, the 5V input must be a minimum of 2A
A PC USB2.0 port provides max. 5V/0.5A (2.5 Watt)
A PC USB3.0 port provides max. 5V/0.9A (4.5 Watt)
Laptop is typically 5V/0.2A (1 Watt)
For power consumption above what a USB port can supply - use an external 5V power supply
The power is dependent on the 5V supply (P=V*A) (Power=Voltage * amps)
1 meter cable

For flat fuses
12Vdc
splash proof hood prevent water ingress
Cable diameter 5mm
Cable total length 24CM
Delivered without fuse
MAX. 30A

INPUT 8-40VDC
OUTPUT 12VDC 10A
Operating temperature -30 ° C to + 80 ° C
not isolated between input and output.
IP68
Overvoltage protection
over -Current protection
Over-temperature protection
Screw terminals - solder eye included
Dim: 110 x 72 x 24 mm
