Web-based I / O module with 16 digital input, dry contact, source, with counter up to 500Hz. 1 x RJ45.

Network-based module with 16 digital inputs
built-in Web server
Web HMI
Support for both Modbus TCP and Modbus UDP protocols
Double watchdog
Wide operating temperature range: -25 ~ + 75 ° C
Built-in I / O
Digital input and counter: 16 channels

ETHI16-I
1,858.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Network10 / 100 Mbit M / RJ45-plug 16 isolated channels with common frame. Logical 1: Floating logic 0: Input loaded for stirrering documents 10 - 30 VDC, 5 W Via clamping protocol mode / TCP, TCP / IP and outlet inputs may act as 32 bit counter, max. Frequency 500 Hzisolation3750 VDCSoftware supplies with configuration software for Windows 2000, XP, Vista , Win7 / 8/10

Forsyning
10 - 30 VDC, 5 W via klemrække
Indgang
16 isolerede kanaler med fælles stel. Logisk 1: Svævende Logisk 0: Indgang lagt til stel
Isolation
3750 VDC
Netværk
10/100 Mbit m/RJ45-stik
Protokol
Modbus/TCP, TCP/IP og UDP
Tæller
Indgange kan virke som 32 bit tæller, maks. frekvens 500 Hz
