Information on USB 3.0
At the end of 2008, USB 3.0 (Super-Speed) was clarified to a transfer rate of 5 Gbps. It is 10 times faster than USB 2.0. Products using USB 3.0 were presented in late 2009 and early 2010.
USB 3.0 supports USB 1.0, USB 1.1 and USB 2.0. This will provide a smooth transition from the current USB 1.0 and 2.0 to USB 3.0. The speed increase comes from extra pins on the USB 3.0 connector. USB 3.0 has 9 pins as...
Information on USB 3.0
At the end of 2008, USB 3.0 (Super-Speed) was clarified to a transfer rate of 5 Gbps. It is 10 times faster than USB 2.0. Products using USB 3.0 were presented in late 2009 and early 2010.
USB 3.0 supports USB 1.0, USB 1.1 and USB 2.0. This will provide a smooth transition from the current USB 1.0 and 2.0 to USB 3.0. The speed increase comes from extra pins on the USB 3.0 connector. USB 3.0 has 9 pins as opposed to USB 2.0 which has only 4 pins. The extra leg also means that where USB 2.0 delivered 500 mA, USB 3.0 can deliver 900 mA. It may eliminate the need for more power supplies that were previously needed due to this limitation.
Subcategories
There are 103 products.
USB ports: 3 external plus 1 internal
OS: Windows 98SE, 2000, XP, Vista and Linux
A small compact box with 4 pcs. 3.0 Hub
Blue LED indicator
Plug and Play
Dimensions; 2.5 x 10.5 x 3.9 cm (H x W x W)
Colour Black
REMAINING STOCK
Extends USB2.0 over Multi Mode LC fiber cable
Up to 200 meters
Can be used for USB 2.0/1.1
Plug-and-play (no driver installation required)
Webcam Resolution up to 1080p@24Hz
Transfers data up to 100 Mbps
Transmitter: DC 5V from USB Port
Receiver: DC 5V Adapter
High speed CAN FD interface via USB port
10-pin terminal block connector for connection to one CAN interface
ISO 11898-2:2016 CAN specification
ISO 11898-1 for CAN and CAN FD
CAN FD supports both ISO-11898-1:2015
CAN FD data rate of up to 8 Mbps
CAN bus speed up to 1 Mbps
Non-standard baud rates are supported
CAN FD port with +5VDC/100mA current output
CAN 2.0A and CAN 2.0B protocols
Listen mode, Loopback mode
CAN FD interface controlled over COM port using simple ASCII commands
Powered by USB port
Includes a USB A/B cable. Cable length: 90 cm
Windows 7 up to Windows 11, Windows Server and Linux OS
Supports Linux SocketCAN (SLCAN)
CanFestival drivers, CANHacker for analyzing CAN frames
API library of C/C++, C#, VB6, VB.NET, Python and LabVIEW
ABS plastic housing
USB A to Straight-Through RS232 serial adapter
With DB9 male
With 3 x data monitoring LEDs (TX, RX, PWR)
COM port assignments are maintained across reboots
Max Baud Rate: 921.6 Kbps | 1, 1.5, 2 stop bits
Odd, Even, Field, Space, No Parity Mode
Hardware Flow Control (CTS/RTS and/or DSR/DTR)
Software Flow Control (XON/XOFF) | Chipset: PL2303-GC
Compatible with Windows®, Mac OS and Linux
USB A to Straight-Through RS232 serial adapter
With DB9 male
With 9 x data monitoring LEDs (TX, RX, PWR)
COM port assignments are maintained across reboots
Max Baud Rate: 921.6 Kbps | 1, 1.5, 2 stop bits
Odd, Even, Field, Space, No Parity Mode
Hardware Flow Control (CTS/RTS and/or DSR/DTR)
Software Flow Control (XON/XOFF) | Chipset: PL2303-GC
Compatible with Windows®, Mac OS and Linux
USB-C to Straight-Through RS232 serial adapter
With DB9 male
With 9 x data monitoring LEDs (TX, RX, PWR)
COM port assignments are maintained across reboots
Max Baud Rate: 921.6 Kbps | 1, 1.5, 2 stop bits
Odd, Even, Field, Space, No Parity Mode
Hardware Flow Control (CTS/RTS and/or DSR/DTR)
Software Flow Control (XON/XOFF) | Chipset: PL2303-GC
Compatible with Windows®, Mac OS and Linux
USB-C to Straight-Through RS232 serial adapter
With DB9 male
With 3 x data monitoring LEDs (TX, RX, PWR)
COM port assignments are maintained across reboots
Max Baud Rate: 921.6 Kbps | 1, 1.5, 2 stop bits
Odd, Even, Field, Space, No Parity Mode
Hardware Flow Control (CTS/RTS and/or DSR/DTR)
Software Flow Control (XON/XOFF) | Chipset: PL2303-GC
Compatible with Windows®, Mac OS and Linux
8 USB ports, 4x USB-A, 4xUSB-C
DIN mounting
USB 1.1/2.0 compatible
480 Mbps, high-speed USB 2.0
10/100 Base-T Fast Ethernet
Current protection 500mA
Network protocols supported: TCP/IP, Static IP, DHCP
Operating temperature: 0 to 55°C (32 to 131°F)
Power supply: 12VDC, 1.5A
CE, FCC
USB3 til multifunction USB3.0+SATA2.5/3.5+SD/TF adapter
- 2 ports hub
- Kortlæser
- Konverter
- Anvendes til 2.5" SATA HDD/SSD, 3.5" HDD (benyt 12v DC PSU), MicroSD og CF kort
- Understøtter: WIN XP, Vista/7/8/8.1/10 og Mac
Mode: Print server, Virtual USB
4 x USB-A female (3 x on the front, 1 x on the back)
2 x RJ45 Ethernet
Antenna for Wi-Fi
Power supply: 5VDC 2A (supplied)
Operating temperature: 0 - 50°C
OS SUPPORT: Windows 10/11, Windows Server 2012R2/2022, Linux 4.9+, Mac OSX (see description)
Mode: Print server, Virtual USB
4 x USB-A female (3 x on the front, 1 x on the back)
2 x RJ45 Ethernet
Power supply: 5VDC 2A included
DC Jack: 3.5/1.3 mm
Operating temperature: 0 - 50°C
OS SUPPORT: Windows 10/11, Windows Server 2012R2/2022, Linux 4.9+, Mac OSX (see description)
MOXA, 1-port RS-232 USB to serial adapter.
Compatible with USB 2.0 and 12 Mbps USB data rate
921.6 Kbps maximum baud rate for super fast data transfer
Drivers are provided for Windows, WinCE and Linux
DB9 male. USB2.0 with 80cm cable
LEDs for displaying USB and TxD / RxD activity
15 KV ESD protection for all serial ports
OS support: Windows 11, 10, 8.1, 8, 7, Vista, ME, and XP Windows Server 2022, 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003, 2000, and NT
Key for USB-B port lock - green
Lock is inserted with this green special key
Other color key cannot release the lock
Key is USBB-LOCK-GN
1 piece. in bag
Colour: green
Material: plastic
USB to 1 x RS422 / RS485, w/ screw terminal
Max speed up to 921.6 Kbit/s - RS422 / 485 port
Select type of port from DIL switch and jumper
Default set to RS422
Supports Win7, 8/8.1, 10, 11, Server 2008 R2, Server 2012 R2, 2022
(WHQL Certified)
Få en COM-port på PC via USB porten
MOXA USB to RS232/422/485 converter.
Kompatibel med USB 2.0
Software selectable RS232, RS422, 4-wire RS485 and 2-wire RS485
Certified drivers for Windows, WinCE 5.0 and Linux
15 KV ESD protection
Supporting Win10
Get a RS485 / RS422 port on the PC via the USB port
Software for choosing a fixed COM port - very useful
Compatible with USB 2.0
12 Mbps USB data rate
921.6 kbps maximum baud rate
Driver for Windows, WinCE, and Linux
Mini DB9 male for terminal block adapter
LED for indication of USB and TxD / RxD activity
15 kV ESD protection for 2 kV optical isolation
2 computers share a device like Fx a printer
Powered from USB no external power supply required
Cables not included
7 port USB3.0 HUB
Supply voltage +7- +48VDC via terminal block
Remember to calculate the power consumption of the ports
The PSU is selected based on the calculation
Surge Protection
Provides great noise immunity
Additional external power supply
YOUR rail kit
