4 opto-isolated digital inputs and 8 digital outputs, open collector, RS485. 10 - 30VDC

8 digital outputs and 4 digital inputs
Open Collector Output
Photocouple Isolation
Digital input channels can be used as 16-bit counters
Configurable Power-on Value settings
Configurable settings for sure value
3750 Vrms insulation voltage
Dual Watchdog
Wide operating temperature range: -25 to + 75 ° C

M485-DIO4-I
186.95 USD
Tax excluded
Quantity
Physically in stock

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

M485-DIO4-I provides four channels of digital input and 8 channels of digital outputs, each of which is equipped with Photocouple isolation. M485-DIO4-I supports output of synktype by means of open collector and input from the sink or source type of wired connections. All input channels can be used as 16-bit counters. There are opportunities to turn both on and safe values. M485-DIO4D-I has 12 LED indicators for DI and DO channel status monitoring. 3750 Vrms intra-module isolation is standard. Hardware specifications for the M485-DIO4-I supports Modbus RTU and DCON protocols that can be configured via software.

Indgang
4 stk. isolerede med fælles plus. Logisk 0: 0 – 1 V Logisk 1: 4 – 30 V
Isolation
3000 VRMS
Udgange
8 stk. optoisoleret med fælles stel “Open collector”: 30 V/375 mA
