12.1" Monitor TFT-LCD, Resistive Touch, IP65 Front, VGA, DVI-D, DisplayPort, 9~48VDC

  • Pack

12 "TFT 4: 3 LCD Resistive Touch
50,000 Hrs LED Backlight Lite
Resolution Up to 1024 x 768
1x VGA, 1X DVI-D, 1x DisplayPort
500 nits Brightness
Designed with aluminum Die-cast Front Frame
IP65 Compatible front panel
Option: Projected Capacitive Touch
9 ~ 48VDC Via 3-pin Terminal Block
Panel, Vesa Mount

This pack contains

I/O Module for Industrial display
x 1
12.1" Modular Monitor
x 1
MON12-CDS
5,300.00 DKK
Tax excluded
Quantity
Physically in stock

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

MON12-CDS is 12.1" LCD display module with resistive touch. It offers resolution up to 1024x768 and 500 nits brightness. MON12-CDS features flat surface and IP65 dust/waterproof front panel. In addition, designed with aluminum die-cast front frame, it is rugged and reliable for industrial environment. With support for Convertible Display System (CDS) technology, MON12-CDS allows you to configure, upgrade and maintain your Convertible Display System easily.

Dimensioner
345 x 265.3 x 57 mm
Driftstemperatur
-20 ~ 75°C
Forsyning
9~48VDC via 3-pin Terminal Block
IP-Tæthed
IP65 Compliant Front Panel
Kontrast
800 : 1 (500 cd/m2)
Opløsning
1024x768 ratio: 4:3
Skærm
12.1"
Touch
Resistive Touch
Weight
5.48kg
