15" TFT panel DVI-I with VGA, DisplayPort, HDMI, 1600 Nits for sunlight 1024x768, 12Vdc 4:3 - Open frame

15" 1600nits Open Frame Monitor for installation.
15" TFT LCD, panel
15" sunlight readable, high brightness (1,600 nits)
Resolution: 1024 x 768
LED backlight
High contrast ratio (1000:1)
Wide temperature range (-20°C~70°C)
12VDC
Low power consumption
BL MTBF: 70,000 hours

MON15-SUN+
Call +45 56 66 20 20 for price
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

We offer OEM screens for special solutions. Contact us regarding size and solutions.​

Farve
Color saturation (NUCS) 69%
Antal farver
16.7M
Approval
CE, FCC
Driftstemperatur
-20°C ~ +70°C
Forsyning
12VDC
Grafik
VGA, DVI-D
Lysstyrke
1600 cd/m2
Opløsning
1024x768
OSD
4 keys (Power switch, menu, +, -) OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Pixels
pitch (mm) 0.297(H)x0.297(V). 85(PPI)
Skærm
15" TFT LED backlight 1024x768
Skærm
304.1(H) x 228.1 (V)
Strømforbrug
12.5W(14.5W with AD Board)
Weight
1.2Kg
