Monitor/TFT

Danbit have a large selection of screens and distributor anywhere from 6 "to large displays for offices, medical, industrial use mm.

General on 4: 3 or 5:4 aspect ratio:

Often you want a 4: 3 TFT led screen to older solutions where the graphics are not to widescreen. But if you eg. want a resolution is 1280 x 1024 then it a 5: 4 format screen you need. Most people believe...

Danbit have a large selection of screens and distributor anywhere from 6 "to large displays for offices, medical, industrial use mm.

General on 4: 3 or 5:4 aspect ratio:

Often you want a 4: 3 TFT led screen to older solutions where the graphics are not to widescreen. But if you eg. want a resolution is 1280 x 1024 then it a 5: 4 format screen you need. Most people believe erroneously that it should be a 4: 3 but it is 1280x960.

Ex. A screen with 4: 3 format.

Resolution 1280/4 = 320, 320x3 = 960 hence resolution of 1280x960

A screen with 5:4

Resolution 1280/5 = 256, 256x4 = 1024 thus resolution of 1280x1024

But note a screen with 5: 4 can be used to 1280x960, but there comes a slightly wider black stripe on the side of the screen.

Monitors / Monitors - Huge selection - DANBIT

Monitor/TFT

There are 75 products.

Showing 1-20 of 75 item(s)
  • 13.3 "Full HD display with...

    13.3 "Full HD display with touch and metal cabinet, 1920 × 1080

    13.3 "full HD display with touch and metal cabinet
    13.3" IPS
    1920 × 1080 16: 9
    10-point capacitive touch
    Brightnes 300cd / ㎡
    Viewing Angle 170 ° / 170 ° (H / V)
    1x HDMI, DVI, VGA
    USB (for touch)
    1x Audio (BNC)
    1x Video (BNC)
    DC 7-24V
    Power Consumption ≤8W
    Operating Temperature -20 ℃ ~ 60 ℃
    Dimensions 333.5 × 220 × 34.5mm (W x H x D)
    VESA 75 and 100
    1.9kg

    Price DKK2,118.00
    Product code: MON13.3"HD
    On the way in
  • 17" Vandtæt monitor,...

    17" Vandtæt monitor, rustfrit stål, LED 250 NITS, 1 x VGA

    17 "IP66 360 ° Waterproof Touch Monitor
    Stainless Steel
    IP66 (Water Resistant)
    Optional: Built-in Touch
    Resistive, Capacitive, Finered Touch
    LED Backlight
    1 x VGA Input
    1 x Jack

    1 x Supply 12V DC
    Temperature 0 ° C ~ 50C
    VESA 100 Mounting

    Price DKK13,697.00
    Product code: MON17"FULLIP66
    On the way in
  • 12.1 "LCD touch monitor,...

    12.1 "LCD touch monitor, readable in bright sunlight, IP65 front, VGA, 4: 3 format

    12.1 "LCD Monitor
    IP65 close front
    Resolution 1024 x 768, 4: 3 format
    800: 1
    1 x VGA interface to 5-wire resistive touch screen
    300 nits
    12V DC input
    input: 110 - 240V
    Output: 12VDC
    Operating temperature: -20 - 70C VESA Church and panel mounting
    Optional: 1000 nits Optional
    : DVI
    Optional: Display Port
    Optional: USB for touch
    Optional: HDMI Kabel

    Price DKK11,088.00
    Product code: MON12"-LPM-RHB
    On the way in
  • 17 "LCD panel monitor, IP66...

    17 "LCD panel monitor, IP66 sealed enclosure, LED backlight, 1280x1024, 250 nits, HDMI, 4: 3 format

    17 "IP66 all around the LCD panel monitor
    LED baggrudslys x | 1 | 1 x HDMI jack
    12VDC
    temperature 0 ° C ~ 50 ° C
    automatic brightness function ( day / night)
    Option - acquisitions: available with touch - choose between resistive, capacitive, infrared
    Option - acquisitions: available with protected glass - with UV protection

    Price DKK15,000.00
    Product code: MON17"PM-IP66
    On the way in
  • 19 "Monitor panel with...

    19 "Monitor panel with touch pcap, VGA, 5: 4 1280 x 1024, 300nits, 12VDC

    19 "industrial panel monitor
    IP54 near the front, vandal proof glass
    Touch: pcap
    1280 x 1024
    300 Nits
    500: 1 to 5: 4 format, the OSD buttons on the front or rear
    VESA mounting holes
    I / O: VGA (15pin D-sub)
    Output:
    12VDC input: 100-240V
    Dimensions: 460 x 392 x 64,5mm < br> Display Dimensions: 376 320 x 301.056mm
    Weight: 6.8Kg

    Price DKK5,982.00
    Product code: MON19"I
    On the way in
  • 8" LCD high bright monitor,...

    8" LCD high bright monitor, touch, 500nits, temperature -30 ° - + 85 ° C, 1x VGA, 2x video 1x audio, 16:9 format

    8" TFT Screen with LED Backlight
    High Brightness 500nits
    16: 9 wide Screen
    Resolution: 640x480 to 1024x768 pixels
    3 x video input, 2 x audio
    Built-In Speaker
    Auto Dimmer Function
    Resitive Touch (USB Interface)
    Supply: 12-24VDC (AC Adapter Included)
    Operating Temperature: -30- + 85 ℃
    VESA 75x75mm

    Price DKK2,356.00
    Product code: MON8"TFT-WT
    Physically in stock
  • 12.1 "TFT LCD screen with...

    12.1 "TFT LCD screen with VGA and touch, 4: 3 format

    Limited Storage!

    Type: 12.1 "TFT Display
    Touch: Resistive Touch
    Resolution: Max. 1024 x 768 - 4: 3 Format
    Signal Inputs: 1 x DB15HDF, 1 x Mini Jack, 1 x USB (Touch)
    OSD: Yes
    Audio: 2 x 2W Speakers
    Power Consumption: Less than 20W
    Weight: 3Kg
    Other: Foot to Screen, 1.8m USB A - A Male Cable for Touch
    Drivers: Windows 2000, XP, Vista, 7 and 8 and Linux
    Power Supply: 230VAC to 12VDC 1.2A Power Supply Included
    Operating Temperature: 0 ° C ~ 50 ° C, Moisture: 10% ~ 90% Non-Condensing
    Contrast: 500: 1
    Brightness : 200cd / m2
    Dimensions (H x W x D) 230 x 315 x 45 mm

    Price DKK1,919.00
    Product code: MON12.1"TFT-T
    Physically in stock
  • 15" LCD monitor 360° IP66...

    15" LCD monitor 360° IP66 stainless steel cabinet, LED back light, 1024 x 768, VGA, 4:3 format

    15" Steel Cabinet Monitor, 360° IP66 Close Cabinet
    Pipe Cable Management - Stainless Steel Cabinet with VESA 100
    LED Backlight Adjustable
    1 x VGA Input
    1 x Jack Jack
    1 x Supply 12VDC
    LCD Screen in 4:3 Format, 250nits
    Temperature: 0°C ~ + 50°C
    Optional: Built-in Touch (Resistive, Capacitive, infrared touch)

    Price DKK12,952.00
    Product code: MON15"IP66-YOKE
    On the way in
