Monitor/TFT

Danbit have a large selection of screens and distributor anywhere from 6 "to large displays for offices, medical, industrial use mm.

General on 4: 3 or 5:4 aspect ratio:

Often you want a 4: 3 TFT led screen to older solutions where the graphics are not to widescreen. But if you eg. want a resolution is 1280 x 1024 then it a 5: 4 format screen you need. Most people believe...

More

Danbit have a large selection of screens and distributor anywhere from 6 "to large displays for offices, medical, industrial use mm.

General on 4: 3 or 5:4 aspect ratio:

Often you want a 4: 3 TFT led screen to older solutions where the graphics are not to widescreen. But if you eg. want a resolution is 1280 x 1024 then it a 5: 4 format screen you need. Most people believe erroneously that it should be a 4: 3 but it is 1280x960.

Ex. A screen with 4: 3 format.

Resolution 1280/4 = 320, 320x3 = 960 hence resolution of 1280x960

A screen with 5:4

Resolution 1280/5 = 256, 256x4 = 1024 thus resolution of 1280x1024

But note a screen with 5: 4 can be used to 1280x960, but there comes a slightly wider black stripe on the side of the screen.

Less
Monitors / Monitors - Huge selection - DANBIT

Monitor/TFT

There are 165 products.

Products per page:
25 50 75 100
Sort by:
Relevance Name, A to Z Name, Z to A Price, low to high Price, high to low
Showing 161-165 of 165 item(s)

Active filters

10.1" Monitor 16:10 format,...

10.1" Monitor 16:10 format, 1500 nits, Highbright, 1920 x 1200, HDMI, VGA USB Type-C, IP65 front, Auto-dimmer, PCAP touch,

10.1" 16:10 Highbright FHD monitor
4k@30Hz
1080p@60Hz
1500 nits
10-point PCAP Touch
1920x1200
Auto dimmer
HDMI, VGA
USB-C both Video and touch
USB cable with screw lock
3.5mm audio output
Supply voltage: 12 -24VDC
VESA 75
Temperature: -20 - +60°C
Dimensions: 251 x 170 x 33
Weight: 820g




Price Call for price
Product code: MON10.1-T-HB
On the way in
Quick view
    • 21.5" IP69K stainless PCAP...

    21.5" IP69K stainless PCAP chassis monitor for food and chemical industry, option 1000 nits

    21.5", FULL HD 1920 x 1080 16.7m Colors
    Brightness 250nits (Possibility: 1000nits)
    IP69K
    VGA, (Possibility HDMI)
    USB for toutch screen control
    PCAP Projected capacitive multi­touch screen, touch with flat design
    A true flat, easy­ to ­clean front surface with edge­to­edge design
    Full IP69K waterproof enclosure
    SUS 316/ AISI 316 stainless steel for food and chemical industries
    Waterproof sealed conduit pipe for cable protection
    Support VESA / YOKE mount
    Optical bonding (Possibility)
    Operation temperature 0°C to 45°C
    541 x 337 x 56.2 mm
    12V DC





    Price Call for price
    Product code: MON21.5-T-IP69K
    On the way in
    Quick view
    • 26" ECDIS DNVGL-CG-0339,...

    26" ECDIS DNVGL-CG-0339, IACS-E10 Marine approved Panel Monitor, 24VDC, PCAP Touch, 16:10 format

    26" DNVGL-CG-0339, IACS-E10, IEC60945 4th marine monitor
    350 nits
    PCAP touch
    Fanless
    IP66 on the front
    Resolution: 1920 x 1200 - 16:10 format
    Active display area: 550 x 344 mm
    1 x VGA
    1 x HDMI 1.4
    1 x DVI-D
    Power supply: Terminal block 24VDC
    DC input: 9 - 36VDC / 55W typical
    Mounting: Panel (Flush) mount with IP66*, VESA100, Bracket mounting
    Vibration: 0.7g@DNVGL CG-0339 (Class A)
    Shock: 15G, 11ms duration
    Optional: Remote control via RS232 D-SUB 9P
    DIM: Day Mode, Dusk Mode, Night Mode
    Dimensions: 621 x 433 x 86 mm
    Cut out dimensions: 596 x 406 mm
    Weight: 12.8 kg

    Price 27,129.00 DKK
    Product code: MON-MAR26"-T
    On the way in
    Quick view
