48VDC 8A DC-DC from 10 - 30VDC 384Watt, Step-up buck. Not galvanically isolated

INPUT 8-40VDC
OUTPUT 12VDC 10A
Operating temperature -30 ° C to + 80 ° C
not isolated between input and output.
IP68
Overvoltage protection
over -Current protection
Over-temperature protection
Screw terminals - solder eye included
Dim: 110 x 72 x 24 mm

MAX Output 12V 0.8A or 9V 1A

USB to DC3.5mm or USB to DC5.5mm

For at forsyne 12V/0.7A skal 5V input være minimum 2A

En PC USB2.0 port giver maks. 5V/0,5A (2,5 Watt)

En PC USB3.0 port giver maks. 5V/0,9A (4,5 Watt)

INPUT 8-40VDC
OUTPUT 12VDC 3A
Operating temperature -30 ° C to + 80 ° C
not isolated between input and output.
IP68
Overvoltage protection
over -Current protection
over-temperature protection

Waterproof DC / DC converter
9-32V to 19V
5 Amp
95 Watts
90% (half load), 87% (full load)
-40 ° c ~ + 80 ° c, IP68
Overvoltage protection
Over-current protection
Over-temperature protection
Short-circuit protection
74 * 74 * 32mm
300g
