RS485 modul til MODBUS 8 x Analoge Input

RS485 Module for load cells
2 analog inputs for 4 wire load cell,
1 excitation Exit
1 Digital input
4 digital outputs
Supply: 10 - 30VDC

RS-485 interface
DCON, Modbus RTU, Modbus ASCII
4 x Analog inputs (+/- 20 mA, 0 ~ 20 mA, 4 ~ 20 mA)
DIN rail / wall mounting
Dimensions 52 x 98 x 27
10 ~ 30 VDC supply voltage
-25 to + 75°C operating temperature

RS485 Module for temperature sensors
1 x input for 2-, 3- or 4-wire PT100,Pt1000 sensor
Nickel Temperature sensor
Supply voltage: 10 - 30vdc

8 channel analog input module for RS485 Bus
16bit resolution
10 measurements per second (total)
for current measurement - shunt with 125 ohm resistance
Supply voltage: 10 - 30vdc / 1.3 watt
Dim: 123 x 72 x 35 mm
with your bracket
