12" Panel monitor, Touch, IP65 front, VGA, DVI-D, HDMI, 500nits, 4:3 format USB (standard) or RS232 touch

12” LCD screen
​IP65 sealed NEMA 4/12 front
DVI, HDMI, VGA
Resolution 1024 x 768 - 4:3
Touchscreen RS232 or USB interface (standard with USB)
Vesa 100 mount, Panel mounting.
OSD
12/24Vdc standard screw terminal
Optional! Rack mounting
Optional! 230 vac

MON12-P+
Call +45 56 66 20 20 for price
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Equipped with a 12.1” TFT XGA LED screen with 1024 x 768 pixel resolutions and up to 16.7 million colors and supports 500 nits high brightness. Supplied with USB (standard) or RS-232 for the touch screen. Graphics inputs HDMI, DVI-D and VGA. To fit into various application environments, the 12.1in IP65 rated touch screen is slim type. Supports panel mount, wall mount, rack mount and VESA arm. With a depth of only 24.95 mm, the feature-rich display can be easily implemented in any space-constrained location.
PG

Approval
CE
Dimensioner
(W x D x H) 311.81 x 54.95 x 250.31 mm (12.28" x 2.16" x 9.85")
Driftstemperatur
0°C ~ +55°C
Forsyning
15 W Screw-type external AC / DC power adapter
Lysstyrke
500 nits
Montering
Vesa 100, Panel mount, Option: Rackmount, Desktop stand, wall mount
Tilbehør
1 x VGA cable 1 x RS232 or USB cable for touchscreen (for touch version) 1 x Audio cable 1 x EU/US power cord (for AC version)
Touch
Resistive touchscreen
Weight
2,35kg
