7 x inputs for temperature sensors (differential), Pt100, Pt1000. Modbus TCP/IP, UTD. PoE

7 x inputs for temperature sensors (differential), Pt100, Pt1000, Ni120, CU100, CU1000, 1 x RJ45 LAN, MODBUS, PoE, 10-30VDC

Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
1 x RJ45 port Ethernet
Dual Watchdog
Operating temperature range: -25 to + 75 ° C
I / O Pair-connection input is mirrored in the other's output
7 x RTD Interface: Pt100, Pt1000, Ni120, CU100, CU1000
Differentialindgange to the temperature sensor, 2 and 3-wire solution
16bit
Power supply: PoE or 10 - 30VDC / 2.5watt

2,950.00 kr
Excl. VAT
Quantity
On the way in
ADD TO CART
Product number ETHIO7RTD-P-I
Get Volume Offer
close

Get Volume Offer


file_download DOWNLOADS
Ask a question
close

Stil et spørgsmål





Download PDF

Specifications

Forsyning 10 - 30 VDC, 5 W via klemrække eller PoE
Indgang 7 stk. differentialindgange (2- eller 3-tråds). Kan bruges med termoføler af typerne Pt, Balco og Ni RTD
Indgangsimpedans 10 kΩ
Maks. hastighed 10 samples/sekund
Netværk 10/100 Mbit m/RJ45-stik
Nøjagtighed maks. ±0,005 %
Opløsning 16 bits
Protokol Modbus/TCP, TCP/IP og UDP

ETHIO7RTD-P-I is specially designed for long distance RTD measurement. It has automatic compensation for three-wire RTD regardless of the length of the wires and provides for open ledningsdetektion to the RTD measurement. ETHIO7RTD-P-I provides 7 channels, each of which can be connected to different types of RTD (Pt100, Pt1000, Ni120, CU100, Cu1000). ETHIO7RTD-P-I are also fully RoHS compliant and has qualification for 4 kV ESD protection as well as 2500 VDC isolation within the module.

3 wire pt100 sensor in metal housing 4 x 80 mm, - 20 - +130°C
3 thread PT 100 sensor in metal house 4 x 80 mm, - 20 ° - +130 ° C, 2 meter cable

3 thread PT 100 sensor
metal house 4 x 80mm
2 meter cable
accuracy: +/- 1 ° C
Temperature range: - 20 - +130°C

218.00 kr
Item Number: PT100+F
On the way in
ADD TO CART
Quick view
