Network module with digital I / O Korenix JETI / O 6550
Channels: 14/8
Digital inputs: 14 pcs., Logic 0: 0 - 4 V, Logic 1: 5 - 30V
Digital outputs: & nbsp; 8 pcs. Open collector, 5 - 40 V 250mA
Isolation: Optical 2500 VRMS for analog and digital inputs and outputs for the power supply
Magnetic 1500 V from the network interface for the power supply
10/100 Mbit m / RJ45 their connector
Operating temperature: - 25 ° C - 70 ° C
Supports Modbus / TCP, OPC server, SNMP. Software included for configuration
For DIN rail mounting
Supply: 10 - 30 VDC via terminal block, Max 1.92 W

Clearance

Ethernet I/O med 12/6 isolerede I/O kanaler.
Med tæller og Integreret WEB-server med nem Javaprogrammering.
12 kanalers DI, 2 kanalers DO, 2 kanalers tæller - Ethernet-based smart I/O
Fjernmonitorering og -styring
Supporterer Modbus, TCP/IP, UDP, HTTP, DHCP
Web-Server: XML, HTML 5, Java Script

Ethernet to 6 Channel Isolated Digital Input / 6 Relay
Modbus TCP
Peer-to-peer fashion

Ethernet module with 2 digital inputs and 1 relay output
2 x digital dry contact - active high by connecting contact
1 x Power relay, 250vac / 5a, 30vdc / 5a
Avoid inductive load to relay
P2P Function that reflects an input to other module output
Supports Modbus / TCP and UDP Slave
Power supplied from PoE or 12 - 48VDC
PoE: IEEE802.3af, Class 1
Operating temperature: - 25 - + 75 ° C
Dim: 98 x 52 x 27 mm
DIN bracket

Extra digital inputs and relay outputs via RS485
3 x digital input
3 x relay output
RS485 interface

The Web server
WEB HMI
Modbus TCP / UDP Modbus
Dual Watchdog
Operating temperature: -25 ~ +75°C
I/O Paie connection - input is mirrored to the other's output
8 x PhotoMOS relay (solid state) COM NO
Relay contact voltage: max 60VDC
Relay contact current: max. 1A
Switching times: on: 5ms, off: 0.3ms
Optical isolation to 3000 Vrms
Supply voltage: 10 - 30VDC / 3watt

Dongle to analyze the data traffic on ZigBee. Supplied with software for analysis of collected data packets

RS485 module with 2-channel strain gauge gauge
high resolution: 16-bit
excitation voltage range: 0 ~ +10 V.
50 Hz Event counter (digital input)
high / low alarm (Digital Output)
Linear Map Function
3000 VDC Intra Module Isolation
Double Watchdog
Temperature Area: -25 to + 75 ° C
Supply Voltage: 10 - 30vdc
Dim: 123 x 76 x 35 mm

RS485 module with 3-axpet Encoder input
1MHz Frequency input
input voltage: Up to 5VDC
Other voltages are with external resistance
32 bit counter
Quadrant, Pulse / Dir, CW and CCW
RS485 port - 1200 - 115.2K Baud
Supply voltage: 10 - 30VDC
Dim: 123 x 72 x 35 mm

RS485 Frequency counter with 2 digital outputs
2 x counter entrance Max. 100kHz
input is Wet / Sink - Max + 30volt
32 bit counter - count up
for frequency and pulses
2 X Digital Output - Open Collector (OC)
Max. OC voltage: 30VDC / 30MA
Supply voltage: 10 - 30VDC
Dim: 123 x 72 x 35 mm
Operating temperature: -25 - + 75 ° C

Accessories
Protective cover
for DIO-RXX and DIO-TXX

2.4GHz Omni directional antenna - dipole
for pipe montage
N-female connector
1 meter RG58 Coax cable
1 pc. RSMA - Male included
Weight: 1.4KG
Length: 45 cm
Diameter: 35mm

5,0 meter kabel til brug mellem I/O-kort og TERM100S

3,0 meter kabel til brug mellem I/O-kort og TERM100S

1 meter kabel til brug mellem I/O-kort og TERM100S

16 digitale indgange med isolation, fælles stel. med PoE

Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ + 75 ° C
I/O Pair connection - the input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
| 1 x RJ45 Ethernet
Power supply: PoE or 10 - 30VDC / 3watt

Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ + 75 ° C
I/O Pair connection - input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
2 x RJ45 Ethernet - Daisy chain
Power supply: PoE or 10 - 30VDC / 3watt
PoE fed NOT proceed to the next module - only data

8 final lecturer 250 VAC 5 A
USB type B with screw terminals
USB 2.0 Full-Speed ​​via USB port
Plug-and-Play
PWR / RUN / ERR LED lamps
For YOUR rail mounting
Operating temperature: -25 to + 75 °

Compact Open Board with 8 relay exits
250V / 10A Only resistive load
Controlled from USB
supply voltage: 5VDC
supply via DC Jack or terminal block
No cabinet
