22" (16:9)
Resolution: 1920x1080
Inputs: VGA, HDMI
Resistive Touch (Option: Projective Glass, SAW) USB. (option: RS232)
OSD
Operating temperature: 0 ~ 50℃
Supply voltage: 12Vdc
Option: 1000 nits
Call +45 56 66 20 20 for price
Monitor/TFT
Menu
Monitor/TFT
Danbit have a large selection of screens and distributor anywhere from 6 "to large displays for offices, medical, industrial use mm.
General on 4: 3 or 5:4 aspect ratio:
Often you want a 4: 3 TFT led screen to older solutions where the graphics are not to widescreen. But if you eg. want a resolution is 1280 x 1024 then it a 5: 4 format screen you need. Most people believe erroneously that it should be a 4: 3 but it is 1280x960.
Ex. A screen with 4: 3 format.
Resolution 1280/4 = 320, 320x3 = 960 hence resolution of 1280x960
A screen with 5:4
Resolution 1280/5 = 256, 256x4 = 1024 thus resolution of 1280x1024
But note a screen with 5: 4 can be used to 1280x960, but there comes a slightly wider black stripe on the side of the screen.
There are 169 products.
17 "LCD monitor
Resolution: 1280 x 1024 to 4: 3 format
IP65 front
250 nits
1 x DVI-D x | 1 | 1 x VGA HDMI
Wall / rack mounting or desktop
Dimensions: 58 x 410.31 x 338.31 mm
12-24V DC
Weight: 3.8 kg without packing / 6,56kg packed
Call +45 56 66 20 20 for price
Industrial 19" rack LCD monitor 18.9"
Standard 18.9" resolution 1440x900 (OPTION! 17.3" 1920x1080)
9U 18.9” LCD panel
Front tempered protective glass
High contrast ratio and wide viewing angle for high screen quality
3mm aluminum front cover
Front OSD button for direct display adjustment
Support SUN native resolution
Optional Touchscreen function
Optional DVI-D and HDMI inputs
Optional DC input power 24Vdc,
Optional 7.3” LCD panel contact sales department
18,448.00 kr
Siemens 6AV7862-2BE00-0AA0
DEMO MODEL - minor impact damage in the aluminum frame (corners)
19" HMI monitor with LED backlight 24V DC
Panel mounting
Widescreen display
Resolution: 1366 x 768
2 x USB 2.0
1 x VGA
1 x Display port (DP)
1 x USB touch interface
IP65 (front)
LED backlight
Touch: analog resistive
Mounting: VESA 100 x 100
Supply voltage: 24V DC
Operating temperature: 0 - 45 degrees
Dimensions: 473 x 297 mm
Mounting plate dimensions: 455 x 279 mm
5,000.00 kr
19 "SXGA LCD monitor
Resolution: 1280 x 1024
4: 3 format
IP65 front
250 nits
1 x DVI-D
1 x VGA
1 x HDMI
1 x USB
resistive touch
Panel / wall / rack or VESA mounting
Dimensions: 482 x 55 x 380 mm
AC 230V supply screw-terminal
Weight: 6kg without packing / 7.5kg packed
12,579.00 kr
9.7" TFT LCD screen
Panel Mounting (can be supplied in OPEN FRAME version)
Resolution: 1024 x 768
1 x AV composite
1 x HDMI
1 x VGA
1 x DVI
4:3 screen
metal
Panel Mount 279.6×203.5×37.6mm, 279.6×195.5×36.1mm(open frame)
Weight: 1600g
-20℃~60℃
Power: 7~24VDC
2,790.00 kr
2 x BNC input
1 x VGA input
1 x S-Video input
2 x BNC output
1 x HDMI
Resolution 1920 x 1080
Contrast 1000: 1
Brightness 250 cd / m2
Designed for 24-hour continuous monitoring of the monitoring system
Industrial quality of metal enclosure
PIP & PBP function
3DNR with noise suppression
Remote ID addressing of remote control
Anti-burn function with automatic image movement
12Vdc supply
6,919.00 kr
450 nits TFT LCD screen
Resolution: 800 x 600
450 cd / m2 (type) / 600: 1 with LED backlight
1 x VGA (15 pin female D-sub)
1 x PC audio (jack)
1 x DC power plug
12V DC
Operating temperature: -30oC ~ 80oC
Weight: 2.5 KG
3,200.00 kr
Wall mounted screen bracket
max. 20 kg
Screen: 23 "~ 42"
VESA Hole Distances: 200 x 200mm, 75 x 75mm, 100 x 100mm, 200 x 100mm
distance to the wall: 44-192mm
swivel angle: 90 °
robust and stable bracket
Dimensions: 220 x 190 x 220mm (B x D x H)
Weight: 1100g
224.00 kr
10.1 ”LCD screen for 1 x VGA
1 x HDMI
1 x USB (touch)
PCAP multitouch (USB)
Resolution: 1280 x 800 @ 60Hz , 75Hz
Brightness: 350 nits (cd / m2)
OSD function
Contrast: 800: 1
Full IP66 / 69K and vandal proof
Operating temp. 0 - +50 C °
Supply 9-36VDC, 15W
For VESA75 or panel mounting
220 x 300 mm (H x B)
9,057.00 kr
Wall mounting bracket for vehicle suspension
IPC-TAB-R10.4
IPC-TABD-R10.4
IPC-TAB-R12
6,582.00 kr
RAM 4.75" Square VESA Base with 2.25" Ball
M5 VESA Mount Screws
M4 VESA Mount Screws
Wall bracket for hanging screens on vehicles
Suitable for item:
IPC-TAB-R10.4
IPC-TABD-R10.4
IPC-TAB-R12
4,617.00 kr
RAM 75mm X 75mm VESA Plate with 1.5 "Ball
RAM Forklift Overhead Guard Plate
Wall bracket for hanging display on vehicles
Suitable for item: & nbsp; IPC-TAB-R7 and IPC-TAB- rA7
4,572.00 kr
Wall bracket for suspension of display on vehicles
Suitable for goods: & nbsp; IPC-TAB-R7 and IPC-TAB-RA7
2,204.00 kr
21.5" LCD screen with PCAP touch
IP30
1920x1080 Full HD
16:9
250 nits
1 x VGA
1 x HDMI
1 x Display port
2 x Speakers - 4W
HDCP
Contrast: 1000:1
Response time: 7 ms
Screen angle: horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Capacitive touch, 10 points (HID, only with OS)
USB touch interface
Plug and play
Vesa mounting 100 x 100
Included: power cable, USB, HDMI, audio
Weight: 4.8 KG
490.5 x 370.5 x 220.5mm
power supply: AC 100 - 240V, 50/60Hz
Energy class B
5,381.00 kr
19 "LCD metal monitor, IP66 front, IP20 back side
1280 x 1024
300 nits
2000: 1, 5: 4
LED backlight
Response time: 20ms
view angle: 178 ° / 178 °
1 x RS-232 (DB9 male)
1 x DVI-D (29-pin DVI-D female)
1 x VGA (15-pin D-sub femlae )
1 x RS232 / 422/485 (software selectable terminal block)
Capacitive touch (PCAP), 4 Points
Supply: 100 to 240 VAC, 24 VDC (18 to 30 V)
- 15 to 55 ° C (5 to 131 ° F)
429 x 387 x 75 mm
Weight: 7,800 g
RoHS, CRoHS, WEEE
Optional: RS-232: TxD, RxD, RTS , CTS, DTR, DSR, DCD, GND
Optional: RS-422: Tx +, Tx-, Rx +, Rx-, GND
Optional: RS-485-2w: Data +, Data, GND
Optional: RS-485-4w: Tx +, Tx-, Rx +, Rx-, GND
25,913.00 kr
19 "LCD metal monitor, IP54 & nbsp; front,
1280 x 1024
300 nits, 2000: 1, 5: 4
LED backlight
Response time: 20ms
viewing angle : 178 ° / 178 °
1 x RS-232 (DB9 male)
1 x DVI-D (29-pin DVI-D female)
1 x VGA (15-pin D-sub female)
1 x RS232 / 422/485 (software selectable terminal block)
Supply: 100 to 240 VAC, 24 VDC (18 to 30 V)
-15 to 55 ° C (5 to 131 ° F)
429 x 387 x 75 mm
Weight: 7,800 g
RoHS, CRoHS, WEEE
Optional: RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Optional: RS-422: Tx +, Tx-, Rx +, Rx-, GND
Optional: RS-485-2w: Data +, Data, GND
Optional: RS-485-4w: Tx +, Tx- , Rx +, Rx, GND & nbsp;
21,351.00 kr
24 "TFT metal monitor with capacitive touch, IP66, IP20
LED backlight
Capacitive touch (PCAP), 4 points
1280 x 1024
Contrast: 700: 1, & nbsp; 1000 nits
Display angle: 160 ° / 140 °
1 x DVI-I (29-pin DVI-D connectors female)
1 x VGA (15-pin D-sub connector female)
1 x RS-232 (DB9 male)
1 x Optional RS232 / 422/485
Supply: 100 to 240 VAC, 24 VDC (18 to 30 V)
Desktop, Panel mounting
6,100 g, 429 x 387 x 75 mm
-40 to 70 ° C
CISPR 32, FCC Part 15B Class A
Optional: RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND < Optional: RS-422: Tx +, Tx-, Rx +, Rx-, GND
Optional: RS-485-2w: Data +, Data, GND
Optional: RS-485-4w: Tx +, Tx -, Rx +, Rx, GND
Call +45 56 66 20 20 for price
24 "TFT metal monitor with capacitive touch, IP66, IP20
LED backlight
1280 x 1024
1000 nits, 700: 1, 4: 3
Display angle: 160 ° / 140 °
1 x DVI-I (29-pin DVI-D connectors female)
1 x VGA (15-pin D-sub connector female)
1 x RS-232 (DB9 male)
1 x Optional RS232 / 422/485
Supply: 100 to 240 VAC, 24 VDC (18 to 30 V)
Desktop, Panel mounting
Weight: 6,100 g
429 x 387 x 75 mm
-40 to 70 ° C
CISPR 32, FCC Part 15B Class A
EN 55032/24
Optional: RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND < Optional: RS-422: Tx +, Tx-, Rx +, Rx-, GND
Optional: RS-485-2w: Data +, Data, GND
Optional: RS-485-4w: Tx +, Tx -, Rx +, Rx, GND
Call +45 56 66 20 20 for price
19 "TFT metal monitor LED backlight, IP66
1280 x 1024
350 nits, 1000: 1, 5: 4
Response time: 5ms
viewing angle: 170 ° / 160 °
3 x BNC
2 x DVI-I (29-pin DVI-D female)
1 x VGA (15-pin D-sub femlae)
1 x RS232 / 422/485 (software selectable terminal blocks)
100 to 240 VAC, 24 VDC (18 to 30 V)
-15 to 55 ° C (5 to 131 ° F)
weight: 9,700 g
483 x 444 x 82 mm
Panel mounting
RoHS, CRoHS, WEEE
Optional: RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Optional: RS-422: Tx +, Tx- , Rx +, Rx-, GND
Optional: RS-485-2w: Data +, Data, GND
Optional: RS-485-4w: Tx +, Tx-, Rx +, Rx-, GND
34,855.00 kr
