Antaira

Supporter 6-Port 10 / 100Tx and 2 x Gigabit Combo Ports
2 x 10/100 / 1000Tx RJ45
2 x 100/1000 SFP Slots
Supporter Auto MDI / MDI-X Function
Store-and-Forward Switching Architecture
8K MAC Address Table
Surge Protection: 2,000 VDC Support
ESD Protection: 6,000 VDC Support
UL Class I, Division 2 Certified
Redundant Power Input Design: 12 ~ 48VDC
Built-in 1 x Relay Output for Power Failure Warning
IP30 Rugged Metal
Wall and DIN Rail Mounting
Operating Temperature EOT: -40 ° to 75 ° C

Supporter 8-Port 10 / 100Tx
2 Gigabit Combo Ports
6 x RJ45 Port 10 / 100Tx
2 x 10/100/100 RJ45
2 x 100/1000 SFP Slots
Supporter Auto MDI / MDI-X
Non-Blocking Switching Fabric
8K MAC Address
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Redundant Power Input Design: 12 ~ 48VDC
1 x built-in relay Output for Power Failure warning
IP30 Rugged Metal Case Design
DIN rail and wall mounting
Operating temperature STD: -10 ° to 70 ° C

Supporter 8-Port 10 / 100Tx
2 Gigabit Combo Ports
6 x RJ45 Port 10 / 100Tx
2 x 10/100/100 RJ45
2 x 100/1000 SFP Slots
Supporter Auto MDI / MDI-X
Non-Blocking Switching Fabric
8K MAC Address
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Redundant Power Input Design: 12 ~ 48VDC
1 x Built-in Relay Output for Power Failure Warning
IP30 Rugged Metal Case Design
DIN Rail and Wall Mounting
Operating Temperature EOT: -40 ° to 75 ° C

5 x 10 / 100Tx RJ45 Fast Ethernet
M12 (D-coded female) Connector IP67 Protected
IP67 Plastic Case Design
RJ45 Port Support Auto MDI / MDI-X
Auto Negotiation Speed, Half / Full Duplex
Store-and-Forward Switching Architecture
Supply Voltage: 12 ~ 48VDC
Power Polarity Reverse Protection
Overload Current Protection
DIN Rail or Wall Mounting
Dimensions: 37.13 x 215.73 x 32.8 mm (W x H x D)
Operating temperature: STD: -10 ° C to 70 ° C

5 x 10 / 100Tx RJ45 fast Ethernet
M12 (D-coded female) Connector IP67 protected
IP67 Plastic Case Design
RJ45 Port Support Auto MDI / MDI-X
Auto Negotiation speed, Half / Full Duplex
Store-and-Forward Switching Architecture
Power Supply: 12 ~ 48VDC
Power Polarity Reverse Protection
Overload Current Protection
DIN-Rail or Wall Mounting
Dimensions: 37.13 x 215.73 x 32.8 mm (W x H x D)
Operating temperature: EOT: -40 ° C to 75 ° C

8 x 10/100 / 1000Base-T (X) RJ45
PoE (P.S.E.) Ports
IEEE 802.3at
Up to 30 Watts Per Port
9.6Kbytes Jumbo Frame
Supply Voltage, Dual Wide Range 12 ~ 36VDC
Auto-Negotiation & amp; Auto-MDI / MDI-X
Store-and-Forward Transmission, Flow Control, IP-30 Housing Design
DIN Rail and Wall Mounting for UL Class I, Division 2 Certified

8 x 10/100 / 1000Tx RJ45 for PoE + (30W / port) IEEE 802.3at for 2 x 100/1000 SFP ports for Auto MDI / MDI-X Function for Store-and- Forward Switching Architecture
20Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC for UL Class I , Division 2 Certified
Supply Voltage: 48 ~ 55VDC
Built-in Relay Output for Power Failure for IP30 Rugged Metal Case Design for DIN Rail and Wall Mounting - Operating Temperature: -40 ° to 75 ° C

8 x 10/100 / 1000Tx RJ45 for PoE + (30W / port) IEEE 802.3at PoE for 2 x 100/1000 SFP ports for Auto MDI / MDI-X Function
Store -and-Forward Switching Architecture
20Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Supply Voltage: 48 ~ 55VDC
Built-in Relay Output for Power Failure for IP30 Rugged Metal Case Design for DIN Rail and Wall Mounting at Operating Temperature STD: -10 ° to 70 DEG C

8 x 10/100 / 1000Tx RJ45 (30W / port)
2 x 10/100 / 1000Tx RJ45
2 x 100/1000 SFP Ports
Auto MDI / MDI-X Function
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC > UL Class I, Division 2 Certified
Power supply: 48 ~ 55VDC
Built-in relay Output for Power Failure
IP30 Rugged Metal Case Design
DIN rail and Wall mounting
Operating temperature STD: -10 ° to 70 ° C

8 x 10/100 / 1000Tx RJ45 (30W / port)
2 x 10/100 / 1000Tx RJ45
2 x 100/1000 SFP Ports
Auto MDI / MDI-X Function
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC > UL Class I, Division 2 Certified
Power Supply: 48 ~ 55VDC
Built-in Relay Output for Power Failure
IP30 Rugged Metal Case Design
DIN Rail and Wall Mounting
Operating Temperature STD: -40 ° to 75 ° C

8 x 10/100 / 1000Tx RJ45 (30W / port)
4 x 100/1000 SFP Ports
Auto MDI / MDI-X Function
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Supply Voltage: 48 ~ 55VDC
Built-in Relay Output to Power Failure
IP30 Rugged Metal Case Design
DIN Rail and Wall Mounting
Operating Temperature STD: -10 ° to 70 ° C

8 x 10/100 / 1000Tx RJ45
PoE+ (30W / port)
4 x 100/1000 SFP Ports
Auto MDI / MDI-X Function
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Supply Voltage: 48 ~ 55VDC
Built-in Relay Output for Power Failure
IP30 Rugged Metal Case Design
DIN Rail and Wall Mounting
Operating Temperature: -40 ° to 75 ° C

12 x 10/100 / 1000Tx RJ45 (30W / port) IEEE 802.3at PoE + 4 x 100/1000 SFP Ports
Store-and-Forward Switching Architecture
8K MAC Address Table
12.2Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Power Supply: 48 ~ 55VDC
Built-in Relay Output for Power Failure
IP30 Rugged Metal Case Design
DIN- Rail and Wall Mounting
Operating Temperature STD: -10 ° to 70 ° C

12 x 10/100 / 1000Tx RJ45
PoE+ (30W / port) IEEE 802.3at
4 x 100/1000 SFP Ports
Store-and-Forward Switching Architecture
8K MAC Address Table
12.2Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Supply Voltage: 48 ~ 55VDC
Built-in Relay Output for Power Failure
IP30 Rugged Metal Case Design
DIN- Rail and Wall Mounting
Operating Temperature: -40 ° to 75 ° C

24 x 10/100/1000Tx RJ45 (30W/port) IEEE 802.3at PoE+
2 x Gigabit combo (2 x RJ45, 2 x FTP)
Auto MDI/MDI-X Function
Store-and-Forward Switching Architecture
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Power supply: 48~55VDC
Built-in relay Output for Power Failure
1U 19" Rackmount design
Operating temperature STD: -10° to 70° C

24 x 10/100 / 1000Tx RJ45 (30W / port) IEEE 802.3at PoE + 2 x Gigabit Combo (2 x RJ45, 2 x FTP)
Auto MDI / MDI-X Function
Store -and-Forward Switching Architecture
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Power Supply: 48 ~ 55VDC
Built-in Relay Output for Power Failure
1U 19 "Rackmount design
Operating temperature STD: 40 ° to 75 ° C

8 x ports 10/100 / 1000Tx, IEEE 802.3at Compliant PoE +
Redundant supply voltage: 24 - 55VDC
Built-in Power Booster Design for PoE / PoE +
Built-in relay output - Power / PoE Failure warning
Bypass Design for Daisy Chain Redundancy
Digital Input / Digital Output
IP67 Rugged Waterproof Metal Design with M12 X-Coded Connection to Ensure Close and Robust Connection
Wall Mounting
Operating Temperature: -10 ° to 60 ° C
Dimensions: 253.57 x 122 x 116.12 mm (W x H x D)

1000Mbit Multimode Media Converter for RJ45
1 x RJ45 10/100 / 1000BaseT
1 x 1000BaseSX / LX with SC connector Multimode
Back-Pressure in Half-Duplex
Auto MDI / MDI -X function in Store-and-forward mechanism
Up to 220m / 550m
Dimensions: 97 x 70 x 26 mm
Operating temperature: 0 - + 50 ° C
Power supply: 5VDC / 2A included

24 x 10/100 / 1000Tx RJ45
2 x Gigabit Combo Ports
2 x 10/100 / 1000Tx RJ45
2 x 100/1000 SFP Slots
Auto MDI / MDI-X Function
Store-and-Forward Switching Architecture
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Redundant Power Input Design: 90 ~ 264VAC
1 x Built-in Relay Output for Power Failure
IP40 Rugged Metal Case Design
1U 19 "Rackmount Design Support
Operating Temperature: -10 ° to 70 ° C

8 x 10/100 / 1000Tx RJ45 IEEE 802.3at PoE + 2 x 100/1000 SFP Ports
Auto MDI / MDI-X Function
Store-and-Forward Switching Architecture
20Gbps Back -Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Power Supply : 48 ~ 55VDC
Built-in relay Output for Power Failure
IP30 Rugged Metal Case Design
DIN-Rail and Wall mounting
Operating temperature STD: -10 ° to 70 ° C
