Remote controlled relay contacts which can be potential free physical relay contacts or as semiconductor contacts (PhotoMos) are widely used in the industry.
If you do not find a module with the inputs and outputs you want - please contact us for advice and guidance. Please provide a quantity and we will be happy to send you an offer.
DANBIT can supply a large selection of modules with built-in digital outputs as physical relays. Some modules have a combination of relay outputs and digital inputs.
They are designed for use in industrial control of machines and processes. Almost all modules support the MODBUS protocol. Power supply from a switch with PoE is also possible.
We can supply modules that are for RS485 series bus. It is gradually replaced by Ethernet-based connectivity, either as wired or wireless (Wifi).
Modules with USB interface are used for smaller systems. This connection has both advantages and disadvantages - easy to connect but unstable as they can lose data connection to the USB port without warning.
Modules with wireless communication on the 2 license-free bands (433MHz and 866MHz) are controllable of gates, lights and other, where greater range is needed and possibly. several recipients.
12 channel power relay output module
RS485 to MODBUS
Communicates via MODBUS RTU
Operating temperature -25 ° -75 ° C
4 kV EFT protection
3 kV Surge Protection
for wall or DIN rail mounting
Modbus TCP Slave Module LAN or Internet
6 x Relay, End Contact 250VAC / 5A, 30VDC / 5A
Avoid inductive load
6 x Digital input. High is 10 - 50V
supply via PoE or 12 - 48VDC
is with I / O Pair Connection - Input is mirrored to exit.
with important "Sale Setting" which sets relays as desired
watchdog which sets relays in "Safe Setting" in error detection
Dim: 123 x 72 x 35 mm
built-in your bracket
RS485 relay box with the display
4 x relay outputs 2 and connect switch 2
4 x isolated inputs
Supply 10 to 30
RS485 Communication port
16 bit counter
ON Voltage Level: 4 V 30 ~ V
OFF Voltage Level: 0 ~ 1 V V
Insulation Voltage: 3750 Vrms
Input Resistance: 3 kΩ, 0.25 W
Dual Watchdog
Spare part
Each Channels Can be software programmed to be input or output
Software routines provided Easily Link to High Level Programs
Switch Selectable Interrupt Level (IRQ2 ... IRQ7)
Presentable de-bounce time in interrupt fashion
10k pull-up resistor for each channel
inlog pi-426
Built-in web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ +75°C
I/O Pair - second module's input is mirrored to output
8 x Power Relay - electromechanical, COM NO
Relay switching time: on: 10ms, off: 5ms
Relay contact voltage and current: 24VDC/250VAC/5A
Electromechanical: Avoid inductive load
Supply voltage: PoE or 12 - 48VDC
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
2-port Ethernet switch for daisy-chain topology
Double watchdog
Wide operating temperature range: -25 ~ + 75 ° C
I / O pair connection. Mirrors the input to output
Built-in I / O to 11 x Power relay: 250VAC / 24VDC 5A
Supply voltage: 10 - 30VDC
PoE voltage is not fed to the LAN port 2
DIN mount
12 connect relays (COM N, O.)
RS485 communications bus
The Web server
WEB HMI
Modbus TCP / UDP Modbus
Dual Watchdog
Operating temperature: -25 ~ +75°C
I/O Paie connection - input is mirrored to the other's output
8 x PhotoMOS relay (solid state) COM NO
Relay contact voltage: max 60VDC
Relay contact current: max. 1A
Switching times: on: 5ms, off: 0.3ms
Optical isolation to 3000 Vrms
Supply voltage: 10 - 30VDC / 3watt
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ + 75 ° C
I/O Pair connection - the input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
| 1 x RJ45 Ethernet
Power supply: PoE or 10 - 30VDC / 3watt
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ + 75 ° C
I/O Pair connection - input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
2 x RJ45 Ethernet - Daisy chain
Power supply: PoE or 10 - 30VDC / 3watt
PoE fed NOT proceed to the next module - only data
8 final lecturer 250 VAC 5 A
USB type B with screw terminals
USB 2.0 Full-Speed via USB port
Plug-and-Play
PWR / RUN / ERR LED lamps
For YOUR rail mounting
Operating temperature: -25 to + 75 °
Compact Open Board with 8 relay exits
250V / 10A Only resistive load
Controlled from USB
supply voltage: 5VDC
supply via DC Jack or terminal block
No cabinet
7 relay outputs (normally open contact)
Glavanisk isolated outputs
Switching time: ON: 5ms
RS485 bus
DIN bracket
10 - 30VDC / 1.5Watt
RS485 I/O module with 4 digital inputs and 5 relay output
4 x digital input (Wet) active with Volt in
digital input as 16 bit counter - 100Hz
5 x relay output - COM, NO
Supply: 10 - 30vdc
DIN
4 x relay outputs 2 end and 2 switch
4 x insulated inputs
supply voltage: 10 - 30vdc
1 x RS485 communication port
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ +75°C
I / O Pair compound - the input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
Supply voltage: 10 - 30VDC / 3watt
Wireless Digital I / O module, Wifi 2.4GHz
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating Temperature Range: - 25 ~ + 75 ° C
I/O Pair-link - the input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
Supply voltage: 10 - 30VDC / 3watt
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
Dual Watchdog
Operating temperature range: -25 ~ + 75 ° C
I/O Pair connection - the input is mirrored in the other's output
8 x Digital input (count): 0 - + 50VDC (500Hz)
8 x Digital Outputs: Open Collector 0 - + 40VDC / 650mA per output
2 x RJ45 Ethernet - daisy chain
Supply voltage: 12 - 48VDC / 4Watt
