Embedded PC / Panel-PC / Industrial PC / POS

15.6", 16 : 9 ratio
Resolution: 1920 x 1080
CPU: Intel® N2930
Ram: 4GB (8GB option)
120GB SSD
3xRS232/485/422
2xUSB3.0, 2xUSB2.0
Mounting: Panel mount, VESA 75x75
Front: IP65 Back: IP22 (all side option)
DC input: 9~32V
Operating temp.: 0°C to +60°C
DNVGL and IEC60945

Intel® Elkhart Lake Atom® x6425E Processor 4-Core
1x DDR4 SO-DIMM, MAX. 32GB
1x M.2 Key E Type 2230 Socket for Intel® CNVi/Wireless Module
Support triple independent display
3x RS232/422/485
2x 1GbE LAN
3x USB 3.2 GEN.2 (10Gbps)
1x USB 2.0
8x Isolated DIO (4xDI, 4xDI)
1x SIM
1x M.2 Type 2230 socket
1x Full Size Mini-PCIe socket
CFM Technology for Power Ignition Sensing Function and PoE Function
EMC Emission / Immunity Standard for Industrial Environment : EN61000-6-4, EN61000-6-2
Safety Certification: UL, cUL, CB 62368-1
Working temperature -40°C to 70°C (needs special WT RAM)
Dimension 204.5x149x41.5mm
Wall/VESA/CDS/Option: DIN RAIL mount
9 ~48Vdc 3 pin terminal

Intel Celeron J6412 Quad Core 2.0GHz
1x DDR4L 3200MHz Max up to 32GB
3x GbE LAN Intel® 225-V
2x RS-232/422/485
1x M.2 SATA, 1x 2.5" SATA
1 x DP, 1 x HDMI
WiFi/Bluetooth/4G/5G optional
DC input 9V~36V
Working tempeture -20°C ~70°C
Windows 10 / 11, Linux

Intel® 13th/12th-Gen Core™ 35W/ 65W LGA1700 CPU
SODIMM MAX. 32GB DDR4 3200
2x 2.5GbE
4x USB3.2 Gen 1 with screw-lock
1x M.2 2280
Gen4 x4 NVMe
1x 3.5"/2.5" SATA HDD/SSD storage
4-CH isolated DI and 4-CH isolated DO
TPM 2.0
VGA + DP dual display outputs
-25°C to 60°C fanless operation (Need special RAM and SSD)
Compact 212 x 165 x 80 mm
Can be wall and DIN mounted needs to be ordered special
1x3-PIN terminal 8~35Vdc remote ON/OFF

Intel® 12th Gen Alder Lake-S Core™ i9/i7/i5/i3 CPU's (max 65 W TDP)
2 x DDR5 SO-DIMM Up to 64GB RAM
HDMI / DP / DVI-I
2x 1GbE LAN
4x RS-232/422/485
2x 2.5" SATA HDD/SSD Bay
1x M.2 Key E Type 2230 Socket for Intel CNVi / Wireless Module
Optional I/O Module Expansion
Optional Power Ignition Sensing & PoE Function
DC input 9 - 48VDC, 3-pin Terminal Block
Wide Operating Temperature -40°C to 70°C
Railway approved
Certification: CB, IEC, EN 50155 (EN 50121-3-2 Only)

15.6" TFT, Resolution 1920x1080
CPU I3-5015U
1000 Nits
Light sensor, (auto dimming on special request)
IP64 front
1xRJ45
2x USB2.0
2x USB3.0
1x RS232/422/485
1x RS232
BT
Wifi
HDMI,VGA output

OS support Windows 10, Linux

7" Display TFT 4:3 1024x600
CPU i5
Touch 10-point PCT (Projected Capacitive Touch)
16 GB of RAM
128 GB SSD
2 x RJ45 Lan
3xUSB
1 x VGA
1 x HDMI
Panel, Vesa mounting
DC12V
Operating temperature -10 to 60°C
OS SUPPORT: Linux / Win10 pro / Ubuntu

CPU Xeon, i9,i7,i5,i3 Gen.10
2x LAN
6x USB 3.2
2x USB 2.0
2x COM
1x PS/2
1x HDMI 4096x2160 at 30Hz
2x DisplayPort 4096x2304@60Hz (according to CPU specifications)
1 x VGA
3 x full-size Mini-PCIe connectors
2 x SIM slots
4 x CMI interface: different I/O moduls see picture
1 x CFM IGN Interface need to be ordere separately
2 x PCI/PCIe slots
Vibration/Shock MIL-STD-810G
CE, UKCA, FCC, ICES-003 Class A, EN50121-3-2 (Rail), IEC/EN 62368-1
REQUEST about additional information with details

CPU support gen.6/7 Intel® Xeon® E3/ 6th & 7th generation Core™ i7/ i5/ i3 processor in LGA1151 socket
Fanless design
4 x 802.3af Gigabit PoE ports by M12 connectors
Support RTC battery service window
2 x mPCIe slots for optional Wi-Fi/ BT/ 3G/ 4G/ GPS modules
1 x M.2 (NGFF) M-Key(2242) socket for storage module
1 x SIM card sockets
Dimensions (W x D x H) 225 x 292 x 90 mm
Wide temperature range from -40°C to 70°C
Wide range DC power input (9~36V)
EN-50155 certified

Supports 10th Gen Intel® Core™ Desktop processors
AI solution for Transportation
Max. 128GB RAM
2x Gbit Lan M12
4x USB
2x SIM Slot
2x 2.5" SSD , RAID 0/1/5
1Xmicro SSD
1x HDMI
1x DVI-D
1 x RS-485, 1 x RS232/485 Isolated
M12 connectores
Up to 10x GbE ports (8x with PoE capability)
10G LAN (need to be ordered special)
Supports Intel® Movidus Vision Acceleration M.2 modules
Supports Wi-Fi 6 CNVi, dual WWAN channels
1x USB Type-C with graphics output for quick setting and diagnostics
EN50155 (2021) / EN45545-2 certified

9"

Resistive Capacitive ARM/NXP i.MX8MMini 1.6GHz

1GB 2GB 4GB

RS-232 RS-485

USB

GLAN

Mini PCIe

eMMC

microSD

19" TFT-LCD 250nits
Resolution: 1280x1024
Front panel IP65
Intel® Celeron® J1900,Quad-core, Up to 2.42GHz
4GB RAM onboard
2 x RJ45
1 x HDMI
4 x USB2.0
6 x RS-232 (2x DB9, 4x terminal)
9-36V DC 3 pin terminal block
-20 ~ 60° C working temperature
Panel Mounting/ 75mm VESA mounting
Dimensions 437.27 x 316.27 x 60.3 mm

Intel Celeron® J6413, Quad Core 1.8 GHz processor
1x 260-pin DDR4 SODIMM. Max. up to 32 GB
Dual independent screen with 2x screen port
1x 2.5 GbE, 1x GbE supports (Wake-on-LAN and PXE)
1x 2.5" SATA HDD bay, 1x mSATA
1x M.2 (B-KEY, 2242/3042/3052, supports 4G/LTE)
1x full-size mini-PCIe for communication or expansion modules
2x RS-232/422/485
3x USB 3.2 Gen2, 1x USB 2.0
M.2
SIM socket
watchdog
9 to 36VDC Wide Range Power Input supporting AT/ATX mode
Wide operating temperature -20°C to 50°C
TPM 2.0 supported
With 1x Universal expansion slot
142 (W) x 101.2 (D) x 41.5 (H) mm
UL listed

24” TFT-LCD with Ultra-high Brightness up to 1,500 nits
Reolution 1920 x 1080
Onboard 8th Generation Intel® Core™ U Series Processor
2x DDR4 SO-DIMM Socket, Supports Up to 2400MHz, 64GB
Supports Triple Independent Display
Integrated USB 3.2 Gen 2 supports up to 10Gbps
M.2 E Key Socket for Wireless Module or Intel CRF Module
Supports Ignition Sensing Function (IGN) (with optional CFM module)
Supports 2x PoE+ Function (with optional CFM module)
1x PCI or 1x PCIe Slot for Add-on Card Expansion: Max. Length 180mm including Bracket (with optional riser card)
Wide Range Operating Temperature -20°C to 70°C
Designed with Rugged Aluminum Die-casting Front Bezel
True Flat IP65 Compliant Front Panel Protection
Supports Panel / VESA / Rack Mounting

11th Gen of Intel® Core™ i5-1135G7 2.4 GHz (up to 4.2 GHz)
17" 1280x1024, PCAP touch
1000 nits (Optical bonding)
1 x SO-DIMM, DDR4 up to 3200 MHz
M.2 M-Key SATA SSD or NVMe SSD
2x USB 2.0
1x RS232
1x RJ45-10/100/1000 LAN
Full IP65
Fanless
VESA mounting, stainless steel
Operating temperature -10°C to 45°C
337.920x270.336 mm
12VDC power input

17" TFT LED Touch screen Display
Screen resolution of 1280 x 1024
Brightness 400 cd/m²
Resistive touch
Intel Celeron Quad Core, 2.0 GHz
4GB DDR3L RAM, expandable to 8GB
VGA, HDMI
1 x LAN Intel 82583V 1000Mbps
3 x USB 2.0, 1 x USB 3.0
1 x COM port
IDEC switch Start/Select/Reset/Key/Stop switch (optional)
IP65 rated water and dust resistant
OS - supports: Windows 7/8/10, Linux, Unix, QNX
Optional: WiFi and Bluetooth
Robust construction
Operating temperatures from -10 to +60°C
External I/O switch
Dimensions: 400 x 390 x 155 mm
Supply voltage: 12-24VDC
Purchase extended supply voltage +9V-36V

15.5" TFT LED Touch screen Display
Screen resolution of 1920 x 1080
Brightness 600 cd/m²
Multi PCAP touch
Intel Core i3-8145U 2.1 GHz
4GB DDR4L RAM, expandable to 32GB
HDMI, DisplayPort
2 x LAN I211-AT GbE LAN
4 x USB 3.0
IDEC switch Start/Reset/Key/Stop switch (optional)
IP65-full: Water and dust resistant
OS - supports: Windows 7/8/10, Linux, Unix, QNX
Optional: WiFi and Bluetooth
Robust construction
Operating temperatures from -10 to +70°C
External I/O switch
Dimensions: 400 x 315 x 130 mm
Weight: 16kg
Supply voltage: 9-36VDC
Power consumption: <35W

19" TFT-LCD Panel PC
IP65 front
Resolution: 1280*1024
250 nits
5-wire resistive touch screen (capacitive touch on request)
Intel Celeron J4125/J6412 CPU / Core i5 /i7
RAM: 1x SO-DIMM DDR4 (celeron) max 16 GB, i5/i7 2x SO-DIMM DDR4 max 32 GB
1 x M.2 2242/2260/2280 SATA
1 x SATA (2.5'' SATA)
1 x M.2 2280 NVME
MPCIe: M.2 3042/3052 for 3G/4G/5G with built-in SIM slot, M.2 2230 WiFi & BT
2x RJ45 Intel i225V (on special request 2 more can be added)
USB: Celeron version: 4*USB2.0+2*USB3.0 (J4125/J6412), i5/i7 version 4*USB3.0+2*USB2.0
COM: 2x DB RS-232/422/485 port, 4*RS232 in expansion port
GPIO: 1* 10 bit GPIO Inside the expansion port
Power supply: 9-36V DC plug
Working temperature: With air flow -10 ~ 60° C
Anti-vibration with SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hour/axis
Anti-shock with SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
437.27x361.27x68.8mm
OS Support: Windows 10 / Ubuntu, CentOS

Fanless design ( Embedded heat pipes cooling solution )
12th/13th Gen CoreTM i9/i7/i5/i3 Processor (Alder Lake-S/Raptor Lake-S)
Up to 60W GPU MXM module expansion
802.3af (15.4W)/802.3at(25.5W) Gigabit PoE ports
DP x2 + HDMI x 1 and DVI x 1 (support 4 independent displays)
Power on/off delay control / configurable ignition power control
Supports TPM 2.0 and Time-Sensitive Networking (TSN)
Two-mPCIe for optional WiFi/3G/4G/GPS or I/O expansion supported
Front-accessible I/O
1 x M.2 B for storge or 5G / LTE +1 x M.2 E-Key for WiFi / BT
1 x M.2 M for NVMe SSD
285x230x 90mm (9.84” x11.50” x 3.54”),Fanless 285x230x110mm (9.84” x11.50” x 4.33”),w/ FAN
DC 9~36V input
CE, FCC Class A, E mark
