Data logning / Data collection / Measurement

Web based controller with 8 digital inputs
Digital High is: +4 - +26VDC
8 x digital inputs Opto-isolated
Common ground
200Hz Counter - 24bit
Tasks: 50 Schedule Planned, 50 Conditional, 20 Tuffer Terms
Email Alarms by defined conditions
Supports encrypted e-mail servers such as Gmail
RTC with NTP server synchronization
No software required
Graph (Logged data)
HTTPS / TLS encrypted
Static or DHCP IP Address configuration
Modbus, SNMP, Remote Service, IP Filtering
On-site update
Supply voltage: 9 - 28VDC
Dim: 98 x 78 x 36 mm

Multi-band 4G LTE Cat.1 controller, logger and alarm
Setup via USB, SMS and HTTP API
USB setup - use USB cable with Mini B male
2 digital "dry contacts". High on contact
2 analog inputs, 0 - 10VDC or 4-20mA input (10bit)
4 relay outputs, COM, NO and NC
1-Wire input for up to 8 Teracom sensors
1 x RS485 for max. 8 MODBUS RTU sensors
Data logger with 70,000 logs
Upload data to HTTP/HTTPS Post in XML/JSON
SMS alarm and Email alarm to 5 recipients
Push mode – XML data is sent via HTTP Post to a remote server. Responses from server may contain relay setup.
10 to 28VDC, 370mA @ 12VDC - additional PSU
Dimensions: 158 x 119 x 34 mm
Weight: 470g
Temperature: -20 - +55°C

Compact environmental meter with e-ink display
CO2 Concentration 0 - 9999 ppm
Temperature 0 - + 50 ° C
Relative humidity 0 - 85%
atmospheric pressure 300 - 1100 hpa < Br> Bluetooth (Via App) or Radio (Via Air-Base)
2 AA batteries up to 3.9 years (10 minute intervals)
Dimensions 70 x 70 x 24 mm
small, portable and easy Using
control air quality to reduce Covid-19 infections

Connect up to 12 "AIR" sensors (optional 100 "AIR" sensors)
Independent local data storage or Cloud
E-mail alert (requires network connection)
SMS alert ( requires supported USB modem)
Measurement data for up to 10 years with 100 sensors
Mesurment intervals: 1, 2, 5, 10 minutes
Power voltage: 12VDC
Operaiting tempeture: 0 °C to 40 °C

DIN bracket
Robust black anodized
47x35 mm

Measuring module for analog in / out and digital in / out
16 x analog inputs 16 bit, (± 10V, ± 5V, ± 2V, ± 1V)
2 x analog outputs 16 bit, (± 10V )
32 x digital inputs / outputs Choose with SW
Total Sample Rate 250khz
Galvanically Isolated for LAN
Digital Inputs / Outputs are TTL / CMOS <3 x Counter 32 Bit, Max. 16 MHz
pulse, increment decoder or pulse measurement
TCP / IP Ethernet
power supply from PoE or externally with 12-40VDC
synchronized for real-time
comes with programming examples in VB, C++ Delphi ,. Net
Can be used with NextView, LabVIEW and Profilab Graphic
14 days free trial with NEXTVIEW 4

1-wire Combi Sensor
Temperature: -20 - +60 ° C +/- 0.6 ° C
Resolution: 0.1 ° C
Humidity (Moisture): 5 -95% Rh +/- 5%
Resolution 0.1%Rh
IP54 Plastic housing, very sturdy
Up to 8 sensors on the same 1-wire
16 bits at temperature
12 bits at moisture
Supply Voltage: 4.5 / 25mW
Dimensions: 74 x 66 x 36 mm

1-wire lysmåler til synligt lys
0 - 83.000lux med 1 lux opløsning
Op til 23bit opløsning
Automatisk fuld skala justering
Kan kaskadekoples via RJ11 stik
Forsynes fra Controller med 5VDC/4mA
Maks. 30 meter kabel
Mål: 85 x 35 x 24 mm
IP30 plasthus med flange

Modbus RTU Master or Slave
RS485
Memory: 4GB
DIN rail Mounting
Supply voltage: 8 ~ 24VAC / 12 ~ 35VDC
Power consumption: 3.5W
galvanically isolated
Software for Windows included
Integrar Web server

Measurement data via mobile network
for Nano SIM card
protocols: HTTP, HTTPS, FTP, SNTP, SMS
collector measurement data from wireless T&D loggers
can serve up to 20 T&D loggers
Free T&D WebStorage Service - Cloud Based
Notifications with SMS by measurement limit
Setup with Bluetooth or USB
Battery operation Supplement. Powered from 9 - 38VDC
Gradual data collection from units of measurement Up to 150meter
SS relay output and digital input
target: 96 x 66 x 39 mm
Weight: 135g

1-axis vibration measurement
Frequency range: 10 Hz to 1K Hz
Amplitude range: ±8g
Data Format:
Acceleration(mg): RMS, Maximum, P-P
Velocity(mm/s): RMS
Top 10 spectrum values(Amplitude/Frequency)
Crest Factor
Supported Modbus RTU Slave protocol
Size: 51 x 30 x 19mm
Supply voltage: 10 - 30VDC
Temp: -25 - +75°C

Pt100 transmitter from sensor to 4-20mA
Working voltage: 24VDC
Accuracy: +/- o.2% full scale
Temperature range: -50 - +200°C
Dimensions: Ø45 mm
Plastic
Weight: 25g
Clamping: Center hole
Zero point adjustment
Adjustment of amplitude

LCD Display
Active kWh (positive and negative), quadrant reactive
Undervoltage, undercurrent, overcurrent, underload
RS485 MODBUS RTU
4G for data (SIM card not included)
Cloud price is not included
Operating temperature -20℃~55℃
IEC 62053-22:2003，IEC 62053-21:200
