Angle bracket for door magnet DOOR-MAGNET-LOCK6 if it is to be mounted on an outward-facing door

Miniature electronic holding magnet for cabinets
Supply voltage 12 VDC, minimum 140mA
Holding force: Up to 36 kg
with Bond sensor - Relay output COM, NC
Bond sensor is a closed indicator - Can inform the controller
Operating temperature: -10 ~ 55ºC
IP65 Stainless steel with epoxy filling
Magnet dimensions: 70 x 38 x 26 mm
Holding plate dimensions: 80 x 32 x 18.5 mm
Weight 350 g

Reading of license plates with the speed of 0-200 km / h
can register license plates for up to four lanes to 5-Megapixel resolution at 30 fps
Built-in infrared white LED (approximately 60 meters)
RJ45 gigabit port
Sound alarm
ONVIF support
Motion detection
WDR
Micro SD
PoE
12VDC / 24VAC
Extended operating temperature -40 - 60 °

4 x Digital inputs NC/NO Type
4 x Analog inputs. 12 bit resolution
0-5V, 4-20mA or 0-20mA
4 x Relay outputs 5A/30VDC, 5A/250VAC
Up to 10 alarm receivers
1 x USB port for setup
GSM 3G 4G mobile network
9-36VDC (12V / 300mA)
Backup Battery 3.7V 1200mAh
Operating temperature -10- + 70 ° C
Customized SMS Alarm messages
APP for iOS and Android
Delivered WITHOUT SIM CARD

Access is controlled by Smartphones via BT
Equipped with call button to request access
United pushbutton with light
Built in sounder
Up to 1000 users
Different user rights
3 functions: access with BT APP, access via query Exit
one administrator
BT: BLE4.2 (Low Energy)
BT range: up to 50 meters, depending on conditions
Compatibility: Android 5.0 and up, iOS9.0 and up
relay contact: NO / COM / NC (switching relay)
Supply voltage: 12 to 24VDC 1A
Operating temperature: -20 - + 70 ° C
Dimensions: 86 x 86 x 38 mm | material: plastic housing
