PC-DELER-M og PC-DELER-S er en ny måde at dele en pc mellem flere brugere.
Systemet er opbygget med en 'master' og en eller flere 'slave'-enheder, som kobles sammen.
En master enhed kan håndtere op til 8 slaveenheder (9 brugere med masterenhed).
Dog ikke over 30 meter mellem master og sidste slaveenhed.
Her er lavet et tilbud med 1 "master" og 4 "slaveenheder.
PC-DELER-M og PC-DELER-S er modulopbygget og gør det nemt og enkelt
at udvide. Hver bruger skifter ved trykknap på modulet. PC-DELER-M og
PC-DELER-S har timeout funktion; når en bruger er færdig med at bruge
den bliver den automatisk ledig til den næste. pc'en kan kun benyttes af en bruger af gangen.
Antal brugere: Maks. 8 slaveenheder (en bruger pr. slaveenhed + en til masterenhed)
Antal meter: Maks. 30 meter mellem master og sidste slaveenhed
Kabel type: Specielt linkkabel mellem master og slaveenhed (DB15 han/hun, 2 meter)
Stik:
PC-DELER-M: 2 x PS/2 hun (tast./mus) og 2 x DB15HDF (VGA og Link ud),
PC-DELER-S: 2 x PS/2 hun (tast./mus), 2 x DB15HDF (VGA og Link ud)
samt 1 x DB15HDM (Link ind)
Ved forlæ¦ngelse af afstanden mellem hver slave-enhed, skal der benyttes et VGA kabel
med alle forbindelser ført igennem.
VGA kabler til forbindelse mellem 2 slave-enheder med alle forbindelser ført igennem:
F.eks:
K-DB15HDM-F+: DB15HD han - DB15HD hun, 1,8 m, sort.
K-DB15HDM-F5+: DB15HD han - DB15HD hun, 5,0 m, sort
K-DB15HDM-F10+: DB15HD han - DB15HD hun, 10,0 m, sort
